OPTIONAL HM-70 HANDHELD CONTROLS AND CONNECTIONS

1.
ON/OFF/MUTE Switch:
turns the unit ON, OFF or MUTE.
2.
Channel Select Switch (CH A/B):
Located in the battery compartment,
the switch is set to Channel B at
the factory.
3.
Power/Charge Indicator:
light glows RED when the HM-70
is powered ON, GREEN when
charging.
4.
Charger Input (CHARGER):
the charging cable from the charger
into this jack for daily charging.
9 | REDCAT User Manual
3
4
1
5
This switch
The
Plug
R E D C A T U s e r M a n u a l
5.
Infrared Emitters:
the emitters as you grip the HM-70
as this could interrupt signal
transmission from the microphone.
6.
Volume Gain Adjustment:
Optimum volume level is
pre-set at the factory and no
adjustment should be necessary.
NiMH
6
Avoid covering
2
