SETTING UP THE REDCAT (cont'd)

MOUNT BASE/WALL BRACKET

Ensure proper orientation of the

bracket as shown in the illustration.

the base/wall bracket against

2. Place

the wall and use a level to confirm

the positioning is straight.

3. Mark the wall where the retaining

screws will be installed.

4. Attach the bracket to the wall

using the mounting screws and

drywall anchors (if required).

the REDCAT firmly by the

5. Holding

bottom quarter, slide the REDCAT

onto the wall bracket as illustrated

below.

R E D C A T U s e r M a n u a l

REDCAT User Manual | 14
