LightSpeed Technologies REDCAT Quick Manual

USING YOUR MICROPHONE
REMOVE FROM CHARGER
Lightspeed microphones require 8 hours to fully charge.
CHANNEL SELECT
Two microphones cannot operate on the same channel.
LT-71
POSITION MICROPHONE
The position of
the microphone
is critical for
proper volume
adjustment.
TURN ON MICROPHONE
SET VOLUME
If necessary adjust volume so you can barely hear your own voice.
Volume set too high will result in system feedback (squealing).
REMEMBER:
TURN OFF AND
RETURN TO CHARGER
LIGHTSPEED TECHNOLOGIES, INC. | www.LIGHTSPEED-TEk.COM | 800.732.8999
LT-71
Grip the
barrel of the
handheld in
the center
section.
LT-71
LT-71
Classroom Audio System
CONNECTING MULTIMEDIA
Interface seamlessly with computers, MP3, DVD, TV and other
audio devices.
3.5mm plug
1
2
3
ASSISTIVE LISTENING AND RECORDING
Send audio directly to an Assistive Listening Device
(ALD) or to a digital recorder for lesson capture and
re-broadcast on school websites.
1
RCA plug
Use your
microphone
to remotely
connect audio to
your system.
3.5mm
plug
3.5mm
plug
RCA
plug
3.5mm
plug
ALD Transmitter
VOL.
ADJ.
SPEAKER OUTPUTS
OFF ON OFF ON OFF ON OFF ON
3
Recording
Device
2
3.5mm
plug
LT-71
250 400 700 1K 1K4 2K5
VOL.
Always +10
ALD OUT AUX OUT ADJ.
0
-10
connect
to the
MIC or
AUX
input
jack.
