- Page 1 SG-3103 Security Gateway with 3 LAN User’s Manual...
- Page 2 Copyright This document is copyrighted in 2002, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improve- ments to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 Our dealers are well trained and ready to give you the support you need to get the most from your Advantech products. In fact, most problems reported are usually minor and are able to be easily resolved over the phone.
-
Page 4: Safety Instructions
ERED REAL-TIME CLOCK CIRCUIT. THERE IS A DANGER OF EXPLO- SION IF A BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANU- FACTURE. DISCARD USED BATTERIES ACCORDING TO THE MANU- FACTURER’S INSTRUCTIONS. SG-3103 User’s Manual... -
Page 5: Table Of Contents
1 Introduction ............2 About the SG-3103............2 Product Features..............2 Hardware ................2 Figure 1.1:Internal View of SG-3103 ......3 Figure 1.2:Bottom View of SG-3103 ......3 Front Panel ................ 4 Figure 1.3:Front Panel of the SG-3103......4 Rear Panel ................. 5 Figure 1.4:Rear Panel of the SG-3103...... - Page 6 SG-3103 User’s Manual Table of Contents...
- Page 7 Introduction This chapter gives information on the SG-3103. Sections include: • About the SG-3103 • Product Features • Hardware • Front Panel • Rear Panel • Packing Content...
-
Page 8: Chapter 1 Introduction
Advantech's SG-3103 Security Gateway is specially designed for internet secure connectivity. It can be used as a triple Ethernet Firewall/VPN/IDS device. The SG-3103, with its industrial grade 1 U chassis and high per- formance computing power, gives network security system integrators and software vendors choices when integrating their security applica- tions. -
Page 9: Figure 1.1:Internal View Of Sg-3103
Figure 1.1: Internal View of SG-3103 Figure 1.2: Bottom View of SG-3103 Chapter 1... -
Page 10: Front Panel
The POWER LED is red under normal conditions. WAN LED When the cable is connected to the WAN, the LED is orange. When the SG-3103 receives data, the other LED flashes green. LAN LED When the cable is connected to the LAN, the LED is orange. When the SG-3103 receives data, the other LED flashes green. -
Page 11: Rear Panel
(cable included) with 8 data bits, no parity, and 1 stop bit, the default speed is 38400 bps. 1.6 Packing Contents The SG-3103 package consists of the following items: • SG-3103 • CPU cooling fan • PS2 Keyboard/Mouse cable •... - Page 12 SG-3103 User’s Manual...
- Page 13 Hardware Installation This chapter tells how to set up the SG- 3103 hardware. Be sure to read all the safety precautions before you begin the installation procedure.
-
Page 14: Chapter 2 Hardware Installation
Chapter 2 Hardware Installation 2.1 RAM Module and CompactFlash Card Installation Using a screwdriver, remove the bottom cover. SG-3103 User’s Manual... - Page 15 Once removed, the SO-DIMM sockets and CompactFlash card socket can be seen. Insert a SO-DIMM into the upper socket first. Chapter 2...
- Page 16 The socket will be tightly secured once the SO-DIMM is pressed down. A second SO-DIMM can be inserted in the lower (shown) socket SG-3103 User’s Manual...
-
Page 17: Hdd Installation
Insert the CompactFlash card into the socket. 2.2 HDD Installation The SG-3103 supports one 3.5” IDE Hard Drive. Chapter 2... -
Page 18: Cpu And Fan Installation
2.4.1 Network Connection Connect a Twisted Pair Ethernet (TPE) network cable to the LAN, WAN, or DMZ port. 2.4.2 Power Connection Connect an AC power to Power connector. The system supports100 V ~ 240 V power in. SG-3103 User’s Manual... - Page 19 Product Specifications This chapter lists the specifications of the SG-3103...
-
Page 20: Chapter 3 Product Specifications
• Transportation temperature/humidity: -20 ~ 75° C, 5 ~ 95% • Operating humidity: 5 ~ 95% @ 40° C, non-condensing • Storage humidity: 5 ~ 95% • Dimensions: 426 x 44 x 273 mm (W x H x D) SG-3103 User’s Manual... - Page 21 CPU Board Reference...
-
Page 22: Appendix A Cpu Board Reference
Appendix A CPU Board Reference The SG-3103 system includes the PCM-9576 board, for detailed PCM- 9576 board specifications; please refer to user’s manual of PCM-9576. Please go to this link http://eservice.advantech.com.tw/eservice/index.asp for more information. SG-3103 User’s Manual...
