Give the event a name.
Fill in the fields according to the type of product:
IN ( ), CAD or SCS.
Note :
Only those fields which correspond to the chosen type
of input must be filled in.
By default, the other fields do not affect the operation
of Omizzy™.
1. Server input: IN ( )
- Enter the "Server input" number in the field
- Enter the type of command received:
- Active OPEN: The event is taken into
account
Omizzy™ server detects on
an IN (
of the external contact from
closed state to open state.
-Active CLOSED: The event is taken into
2. Input: CAD
- Enter the group and the channel in the field.
- Enter the type of command received:
- Active ON: The event is taken into account
when an On command is
received by the Omizzy™
server.
- Active OFF: The event is taken into account
when an Off command is
received by the Omizzy™
server.
when the
) input the change
account when the
Omizzy™ server detects
on an IN ( ) input the
change of the external
contact from open state to
closed state.
3. Input: SCS
- Enter the number of the jumper in the AUX
selection.
- Enter the type of command received:
- Active ON: The event is taken into account
when an On command is
received by the Omizzy™
server.
- Active OFF: The event is taken into account
when an Off command is
received by the Omizzy™
server.
4. Locking input
It is possible to lock the Omizzy™ server via one
of the two input signals (IN, CAD).
This locking prohibits access to the control pages
of the server.
The locking is active if the padlock is displayed on
the initial page.
Locking triggered by external events can be
performed via two types of command on an input
(via a CAD pushbutton or via a switch on input IN).
If the server has been locked by pressing a CAD
pushbutton, unlocking it from the installation page
of the server unlocks it permanently.
To lock it again, click on the "Lock" button or press
the CAD pushbutton again.
If the server has been locked by operating a switch
(IN input), unlocking it from the installation page
of the server unlocks it temporarily. If the server is then
not used for a period of 10 minutes, the server
checks the position of the switch and automatically
re-locks itself if the switch is in the "Locked" position."
