Méthod 2 :
(This method requires the user to be present in
the house in order to set the parameters)
Give the heating a name.
Click on "Select".
Click on "OK" in the window which appears on
the screen.You have a period of three minutes
to press the button on the CAD receiver (cable outlet)
corresponding to the zone to be configured.
The server then communicates with the heating
management unit and automatically fills in the group
and zone fields.
Important :
If the figure "0" appears in the group, either the commu-
nication has failed (restart the procedure), or the period
within which the button must be pressed has been
exceeded (maximum period: 3 minutes).
Note:
It is not possible on the same server to configure a On / Off
heating zone and a manager heating zone.
It is then possible to display the status of the installation
and control the convectors in the house from
the "Control/Heating" menu.
On the "Control/Heating" page, the status of
the connected products is updated automatically
every minute.
For a french installation, the "Blue/White/Red" day
(TEMPO tariff*) and the "Off-peak/peak" tariff
information is constantly displayed and regulary
updated.
* "TEMPO tariff": offer tariff available only at EDF
(Electricity of France).
Convector status icons:
: Anti-frost/OFF;
: Comfort/ON ;
: Reduced comfort;
: Economy ;
: Blue day ;
: White day ;
French
installation
: Red day ;
: Peak ;
: Off-peak.
: Indicates that no signal is being received.
only
