Control of roller shutters

The roller shutter control function controls the opening
and closing of the shutters on a house via CAD
mains-borne signalling products.
Installation
- CAD :
~
0 V
- 4 0
S
1 0 0 H z
S C
6 0
5 0 /
D
C A
"Roller shutter control" commands are transmitted via
the CAD link.
Each CAD product is coded with a group number
and a channel number.
Channel
selector
Group
selector
Example of compatible products:
- 841 15/16.
Configuring the Omizzy™ server
Click on "Installation", "Shutters".
Click on "Add" to add and configure a new item.
Click on the name of an existing item to change its
parameters.
Give the roller shutter a name.
e r
P o w
V
- 1 2
7 ,5
1 A
4
3
2
Enter the group and channel settings.
1
2
1
N
L A
It is also possible to associate a camera with
I
I I
~
0 V
-4 0
S
1 0 0 z
0 H S C
5 0 /6
D
C A
the device, in order to display the image of the house
during remote viewing.
From the "Control/Shutters" menu, it is then possi-
ble to control the opening and
closing of the various shutters which are identified.
Each time a command is given, the states of
the shutters are displayed, then updated every
10 minutes.
Shutter status icons:
: Shutter open ;
: Shutter closed ;
: Shutter stopped ;
: Indicates that no signal is being received.
