Code Alarm CA 6551 Owner's Manual page 45

26
4 - Siren I Horn: This feature selects which output(s) will sound the system's
arm/disarm chirps. This feature does not effect the triggered state of the security
system and during a triggered cycle, both the siren and horn outputs will activate
respectively.
5 - Security: Controls security functionality - ON / OFF.
ON - Full security functionality.
OFF - The security system does not trigger. Panic, Remote Start and all
other convenience features opeiate as normaL
6 - Hi Jack: Controls hi jack mode - ON / OFF.
OFF - Standard security system operation.
ON - Enables Hi Jack mode functionality as described in the owners manual
Feature Bank 3 - Output Control
1 - Extended Lock Pulse: Controls the timing of the BLUE and GREEN lock output
wires.
1 Second - Single 1 second lock pUlse, single 1 second unlock pulse.
3.5 Seconds - Single 3.5 second lock pUlse, single 3.5 second unlock pulse.
1 Second Lock, Double Pulse Unlock - Single 1 second lock pUlse, double 1
second unlock pulse.
30 Second Lock, Double Pulse Unlock - Single 30 second lock pUlse, double
1 second unlock pulse.
Double Pulse Lock, 1 Second Unlock - Double 1 second lock pUlse, single 1
second unlock pulse.
2 - Factory Disarm: Controls the timing of the LT. GREEN/BLACK factory disarm
wire on the 6 pin output harness only and does not change the output of the factory
disarm wire on the 4 pin alternate output harness.
Factory Disarm - Single 1 second pulse with unlock and remote start
activation.
2nd Unlock - Same ouput as unlock with 2nd press of unlock only.
Start Status - Continuous ( - ) output during the remote start cycle.
2010 Audiovox Electronics Corporation. All rights reserved.
