CA 610 Owners Manual
CAUTION!
Be certain that the vehicle is outdoors before using this or any re-
mote vehicle starting device. A running engine produces dangerous
carbon monoxide fumes which can be harmful or fatal if prolonged
exposure occurs. DO NOT remote start the vehicle if the car is
garaged
128-6530
1 of 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CA 610 and is the answer not in the manual?

Questions and answers

Related Manuals for Code Alarm CA 610

Summary of Contents for Code Alarm CA 610

  • Page 1 CA 610 Owners Manual CAUTION! Be certain that the vehicle is outdoors before using this or any re- mote vehicle starting device. A running engine produces dangerous carbon monoxide fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle if the car is...

  • Page 2: Arming The System

    Your Remote Start Alarm System has many features and available options some of which are selected at time of installation. Consult your installing dealer for options that may have been installed and are not listed. ARMING THE SYSTEM: 1. Turn the engine OFF, exit the vehicle, and close all doors, hood and trunk. 2.

  • Page 3: Protection While The System Is Armed

    ARMING THE SYSTEM: If the passive arming feature has been selected: 1. Turn the engine OFF, exit the vehicle, and close all doors, hood and trunk. The dash mounted LED will begin to flash rapidly indicating that the 30 second passive arming timer has begun. If the LED does not begin to flash rapidly, then you have left a door, hood, or trunk ajar.

  • Page 4: Disarming The System

    DISARMING THE SYSTEM: As you approach the vehicle, press and release the Disarm button on the keychain transmitter. The parking lights will flash 2 times, the siren will chirp 2 times, and the dash mounted LED will turn off. If you have the optional door lock/unlock circuit installed, the doors will unlock. If you have the optional entry illumination circuit installed, the interior light will turn on for 30 seconds or until the ignition key is switched on.

  • Page 5: While The System Is Sounding

    alarm system had been triggered in your absence. Before turning on the ignition key, examine the dash mounted LED's flash pattern. The number of flashes identifies the triggered zone. For additional information, refer to INTRUSION WARNING SIGNALS found later in this manual. NOTE: If the optional 2 step door unlock circuit is installed, when the unlock transmitter button is activated, the drivers door only will unlock, pressing the unlock button a second time will cause all doors to unlock.

  • Page 6: Valet Switch

    VALET SWITCH: The valet switch allows you to temporarily bypass all alarm functions, eliminating the need to hand your transmitter to parking attendants or garage mechanics. When the system is in valet mode, all alarm functions are bypassed, however the remote panic feature and remote door locks will remain operational.
  • Page 7 center for programming details. The system comes from the factory with a pre-programmed override code of 11.To change this default override code, do the following: Disarm the system by use of the transmitter, or by use of the emergency override sequence. Turn the ignition switch to the ON position. Within 10 seconds, press and release the valet/override switch, 3 times.

  • Page 8: Eliminating The Normal Arm/Disarm Chirps

    Within 5 seconds, press and release the pushbutton switch 1 time. Within 5 seconds, turn the ignition switch OFF then ON. Within 5 seconds, press and release the pushbutton switch 1 time. Turn the ignition switch OFF then ON and start the vehicle. NOTE:If you have changed the programmed override code then substitute your new code tenths for step 2 above, and units for step 5 above.
  • Page 9 Unlock buttons will, if the option is installed, lock and unlock the doors respectively. While in the panic mode, anytime the unlock button is pressed, the panic feature will continue for the allotted 30 seconds, however, the security system will be disarmed allowing the vehicle to start. SAFETY (Red Handled ) CONTROL SWITCH: The control switch allows you to temporarily disable the remote starting function of your Remote Start system.
  • Page 10 NOTE: The engine will stop running before the expiration of the pre- programmed run timer if you complete any of the following: 1. Press and release trunk/key button of your keychain transmitter two times within 2 seconds. 2. Depress the brake pedal. 3.
  • Page 11 CANCELING THE AUTOMATIC START TIMER: To cancel the automatic start timer do one of the following: Start the vehicle using the ignition key and depress the brake pedal. Remote start & stop the vehicle using your keychain transmitter. ADDITIONAL REMOTE FUNCTION CHANNEL 3: The system has an additional feature, (Channel 3) ,that can be connected to the Trunk Release.
  • Page 12 CA-610 SYSTEM FUNCTIONS AT A GLANCE ALARM DASH LED INDICATORS RAPID FLASHING PASSIVE ARMING SLOW FLASHING ARMED DISARMED ON SOLID VALET MODE 3 FLASH... PAUSE INTRUSION ZONE 3 2 FLASH...PAUSE INTRUSION ZONE 2 1 FLASH...PAUSE INTRUSION ZONE 1 ALARM SIREN CHIRP INDICATION 1 CHIRP* 2 CHIRPS* DISARMED...
  • Page 13 Code Systems, Inc. Limited Lifetime Warranty Code Systems, Inc. Limited Lifetime Warranty A Code Systems Inc. (“CODE”) vehicle comfort, convenience and security system sold to a retail consumer purchaser by an authorized dealer of CODE and installed by an authorized dealer of CODE is warranted by CODE to the original retail consumer purchaser to be free from defects in workmanship and materials for the lifetime of the vehicle in which the system was originally installed.
  • Page 14 Code Systems, Inc. Limited Lifetime Warranty - Cont Code Systems, Inc. Limited Lifetime Warranty - Cont CODE shall not be held responsible for any removal and/or reinstallation charges of a defective system, damage to or theft of the vehicle or its contents, or any incidental or consequential damages caused by any failure of the system to function properly.
  • Page 15 Plan duration: 3 Years from the date of installation. Plan amount: Maximum allowable value equal to insurance deductible or up to $2,500 whichever is less. Conditions of the Theft Protection Program: The Theft Protection Program is non-transferable and non-assignable. The system must be installed by an authorized CODE dealer. Vehicle must be less than three (3) model years old at the time of installation.
