Patton SmartNode SN4960 User Manual page 55

SmartNode 4960 User Manual
Table 13. SmartNode Models and their Unique sysObjectID (Continued)
SmartNode Model
SN4961/4E120V
Note
The SysObjectIDs for the SN4960 G.SHDSL models are the same as the
corresponding non-G.SHDSL models listed above.
According to table 13, an SNMP get request to .iso.org.dod.internet.mgmt.mib-2.system.sysObjectID of a Smart-
Node 4960/1E15V/UI device reads out a numeric OID of 1.3.6.1.4.1.1768.100.4.10.1, which represents a
SmartNode 4960/1E15V/UI device. The mapping of the sysObjectID to each of the SmartNode model is real-
ized with the SmartNode product identification MIB.
IMPORTANT
Identification of the SmartNode devices via SNMP
SysObjectID
.iso.org.dod.internet.private.enterprises.patton.products.sn49xx.10
1.3.6.1.4.1.1768.100.4.10.20
The SNMP agent running in SmartWare is SNMP version 1
(SNMPv1) compliant. SNMP version 2 (SNMPv2) and SNMP
version 3 (SNMPv3) are not currently supported.
B • Specifications
56
