SmartNode 4960 User Manual

SN4960 model codes

The SmartNode 4960 series consists of several models. They differ in the number of PRI ports and voice chan-
nels supported. All models come equipped with two 10/100/1000Base-T Ethernet ports. The SmartNode
4960 PRI ports and voice channels are listed in
table 3.
SN4960/1E24V/UI
SN4960/1E30V/UI
SN4960/4E24V/UI
SN4960/4E30V/UI
SN4960/4E48V/UI
SN4960/4E60V/UI
SN4960/4E96V/UI
SN4960/4E120V/UI
Table 3. SmartNode 4960 models with integrated G.SHDSL interface
SN4960/1E24V2GS/UI
SN4960/1E30V2GS/UI
SN4960/4E24V2GS/UI
SN4960/4E30V2GS/UI
SN4960/4E48V2GS/UI
SN4960/4E60V2GS/UI
SN4960/4E96V2GS/UI
SN4960/4E120V2GS/UI

SN4961 model codes

The high precision SmartNode 4961 models have a Stratum III clock. The Stratum III clock provides a clock
source of < 5 ppm. For PBXs that used to rely on PSTN for accurate clock source, the SmartNode 4961 can
provide a PSTN-equivalent high precision clock. The popular DECT PBX needs such high precision clocks.
Note
SmartNode 4960 overview
table
Table 2. SmartNode 4960 PRI Ports and Voice Channels
Model
Model
For high precision clock models, replace SN4960 with
the model code.
2. The SmartNode 4960 G.SHDSL models are listed in
PRI Ports Voice Channels
1
1
4
4
4
4
4
4
PRI Ports
1
1
4
4
4
4
4
4
1 • General information
24
30
24
30
48
60
96
120
Voice Channels
24
30
24
30
48
60
96
120
in
16
