This is HIGH-POWER item; please DO NOT USE THE SAME OUTLET WITH OTHER
HIGH-POWER HOUSEHOLD APPLIANCE like air-conditioning etc.
Please choose an outlet exclusively for the machine and make sure the fuse is 10A.
Special tips:
1.
Before installation and operation, please read this operation manual carefully.
2.
Please save this manual for future reference.
3.
Product may vary slightly from the item pictured due to model upgrades
CONTROL
http://www.lifespanfitness.com.au/
USER'S
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Control and is the answer not in the manual?

Questions and answers

Related Manuals for LifeSpan Control

Summary of Contents for LifeSpan Control

  • Page 1 CONTROL USER’S MANUAL This is HIGH-POWER item; please DO NOT USE THE SAME OUTLET WITH OTHER HIGH-POWER HOUSEHOLD APPLIANCE like air-conditioning etc. Please choose an outlet exclusively for the machine and make sure the fuse is 10A. Special tips: Before installation and operation, please read this operation manual carefully.

  • Page 2: Table Of Contents

    Table of Contents 1 Brief Description………………………………………………………………………………2 2 Main Technical Features…………………………………………………………………………2 3 Tips for safety…………………………………………………………………………………3-4 4 Installation………………………………………………………………………………………4 5 Use and Operation…………………………………………………………………………… 4-6 6 Maintenance………………………………………………………………………………… 7-11 7 Guides for malfunction…………………………………………………………………11-12 8 Warranty……………………………………………………………………………………12 9 Error and self-inspection………………………………………………………………12-13 10 Installation Sketch…………………………………………………………… 13-16 - 1 -...

  • Page 3: Brief Description

    1. Brief Description Treadmill CONTROL (diagram 1) can help complete your goal of keeping fit together with unique and elegant appearance. Easily read panel parameter. Easily operated folding system realizes space-saving. Auto speed range 1-20km/h and auto incline range1-20. Evaluating bodyfat and MP3 are available .

  • Page 4: Tips For Safety

    3. Tips for Safety Insert the power plug into the socket directly. Current load should not be less than 10A. The constant running time is less than 2 hours, max weight is less than 250kgs. Place your treadmill on the clean floor，not on the thick carpet, otherwise it will not convenient for ventilation.

  • Page 5: Installation

    3.14 Please stop exercising immediately and consult your doctor if you’re feel giddy, surfeit, thorax ache or other symptoms. 3.15 Please drink adequate water after taking exercises on our treadmill for more than 20 minutes. 4. Installation: See “Installation sketch” 5.
  • Page 6 （4）“off” Press this key to make machine stop working. （5）“speed up” Under running condition, press this key, speed can be speeded up to the one you need. （6）“speed down” Under running condition, press this key, speed can be speeded down to the one you need.
  • Page 7 position which is on the frame. Place the safe key to the appointed position. After a few seconds, panel will show that the machine is ready. 2) Nip another end of safe key to your clothes, and stand on the footplate on both sides.

  • Page 8: Maintenance

    Never use solvents, as they can cause damage to the treadmill. • Inspect the power cord. If the power cord is damaged, contact Lifespan Fitness. • Make sure the power cord is not underneath the treadmill or in any other area where it can become pinched or cut.
  • Page 9 It may be necessary to lubricate your treadmill running deck at least once every six months to maintain optimal performance of your treadmill (refer to section 4.4 for information). Only use lubricant provided by Lifespan Fitness! Please contact Lifespan Fitness with questions about applying lubricant to your treadmill.
  • Page 10  On a monthly basis, vacuum underneath your treadmill to prevent dust build up. Once a year, you should remove the black motor shield and vacuum out dirt that may accumulate. General Care  Check parts for wear before use. ...
  • Page 11 If the surface is dry to the touch, apply a suitable silicone lubricant. We recommend you use a silicone based spray to lubricate your Lifespan Treadmill. This can be purchased from your local sports Retailer or a local hardware store.

  • Page 12: Guides For Malfunction

    Turn the electrical switch is placed to “0” to “1” creepage switch is Replace creepage switch not right Meter can’t display The meter control Pull the bolt out and open line and control the motor cover and panel are reconnect it unconnected...

  • Page 13: Warranty

    Treadmill gives the following error code if anything wrong，please contact the processional service people soon if it happen. E1：communication failure E2：overspeed protection E3：sensor test error E4：incline error E5：over current protection E6：control self-test error E7：safety switches cut off - 12 -...
  • Page 14 Self-inspection No need to self-inspect unless special situation. If necessary, please do it under the instruction of professional technical people or sales because of the high voltage. a，open up motor cover b，Press the switch on the motor drive board c，Turn on the treadmill d，Undo the switch Treadmill raises up first, and then drops down。Self-inspection is completed 20 seconds after dropping down.
  • Page 15 - 14 -...
  • Page 16 - 15 -...
  • Page 17 - 16 -...
  • Page 18 Proofreading has been carefully done to the manual, if there are printing mistakes, please kindly understand. If pictures and the real product do not match, please take the product as the final and correct one. If any improvement on function and specification, please kindly understand if you are not informed. - 17 -...
