LifeSpan Delta 1.1 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Delta 1.1 Treadmill
$ $
Product may vary slightly from the item pictured due to model upgrades.
Read all instructions carefully before using this product.
Retain this owner's manual for future reference.
NOTE:
This manual should not be used to guide your purchasing decision. Your product, and the contents inside its carton, may vary
from what is listed in this manual. This manual may also be subject to updates or changes. Updated manuals are available
through our website at
www.lifespanfitness.com.au
USER MANUAL
Find the
Digital Manual
Online
$ $

Advertisement

loading
Need help?

Need help?

Do you have a question about the Delta 1.1 and is the answer not in the manual?

Questions and answers

Related Manuals for LifeSpan Delta 1.1

Summary of Contents for LifeSpan Delta 1.1

  • Page 1 Delta 1.1 Treadmill USER MANUAL Find the Digital Manual Online Product may vary slightly from the item pictured due to model upgrades. Read all instructions carefully before using this product. Retain this owner’s manual for future reference. NOTE: This manual should not be used to guide your purchasing decision. Your product, and the contents inside its carton, may vary from what is listed in this manual.
  • Page 2 TABLE OF CONTENTS Important Safety Instructions ....... 03 II. Important Electrical Information ......05 III.
  • Page 3 I. IMPORTANT SAFETY INSTRUCTIONS WARNING: Read all instructions before using this treadmill. It is important your treadmill receives regular maintenance to prolong its useful life. Failing to regularly maintain your treadmill may void your warranty. DANGER To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to cleaning and/or service work.
  • Page 4 11) Never drop or insert any object into any openings. 12) The treadmill is intended for in-home use only and not suitable for long time running. 13) To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug from the outlet.
  • Page 5 II. IMPORTANT ELECTRICAL INFORMATION WARNING! 1) NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Route the power cord away from any moving part of the treadmill including the elevation mechanism and transport wheels. 2) NEVER operate treadmill on Generator or UPS power supply. 3) NEVER remove any cover without first disconnecting AC power.
  • Page 6 III. IMPORTANT OPERATING INSTRUCTIONS 1) Insert the power plug into the socket directly. 2) The constant running time is less than 2 hours. Be sure to read the entire manual before operating your machine. 3) Understand that changes in speed and incline do not occur immediately. Set your desired speed on the computer console and release the adjustment key.
  • Page 7 IV. ASSEMBLY INSTRUCTIONS The following figure shows the scatter diagram of the parts installed in the whole machine table. Open the packaging box, and you can remove the following parts from the box. PARTS LIST Description Description Part No. Specs Qty.
  • Page 8 V. ASSEMBLY INSTRUCTIONS STEP 1 Open the packaging box, remove the materials listed above, and lay the main components flat on the ground. Caution: Hold the column securely with one hand during installation to prevent it from falling and causing injury. Be careful not to squash any cables.
  • Page 9 Caution: When folding the console, ensure the internal wires are not pinched and verify that all wire connections are secure. While tightening the screws, support the electronic console with your hand to prevent it from falling. STEP 3 1. As shown in the image on the left, first fold the electronic console backward.
  • Page 10 STEP 5 1. Attach the safety key (48) to the console. Then, connect the power cord (33) to the wall power outlet. Do not use a power board or plug with a high-powered electrical equipment. | ASSEMBLY INSTRUCTIONS...
  • Page 11 VI. FOLDING AND UNFOLDING FOLDING INSTRUCTION 1. Hold the machine in position A with both hands and push it up slightly, until you hear the sound of the air pressure rod sleeve against the air pressure rod B. Note: The wire rope assembly needs to be unplugged when folding.
  • Page 12 VII. OPERATION GUIDE 5 0 % 4 0 % 6 0 % 3 0 % 7 0 % 2 0 % 8 0 % 1 0 % 9 0 % 1 0 0 % 1. WINDOW DESCRIPTION: 1. Calories Window: Displays the number of calories burned during exercise. 2.
  • Page 13 2.3 START Button 1. Press to start the treadmill. 2. After pressing, the treadmill will start at the lowest speed (or the program’s default speed) following a 3-second countdown. 2.4 STOP Button 1. Press to pause the treadmill gradually. 2. All data will be retained during the pause. 3.
  • Page 14 3.2 Countdown Modes - Press the MODE button to cycle through the available countdown options: Time Countdown → Distance Countdown → Calorie Countdown. - The corresponding window will display the default value, which will blink to indicate it can be adjusted. - Use the SPEED ▲...
  • Page 15 7. MOTION PARAMETER DISPLAY AND SETTING RANGES Parameter Display Range Manual Mode Default Program Default Setting Range Speed 0.8 – 12 KM/H — — 0.8 – 12 KM/H Incline 0% – 15% — 0% – 15% Time 0:00 – 99:59 (min:sec) 30:00 30:00 5:00 –...
  • Page 16 11. ERROR CODES AND TROUBLESHOOTING TABLE Error Code Reason Suggestion Solution Poor communication between - Disrupted communication between - Check and secure all console and controller console and controller. connections between console - Loose or damaged communication and controller. cables. - Inspect and replace damaged - Faulty communication circuits.
  • Page 17 This electric treadmill is pre-lubricated, but regular lubrication is essential for optimal performance and longevity. Why Lubricate? Friction between the running board and running belt affects the treadmill’s performance and lifespan. Regular lubrication reduces wear and ensures smooth operation. Lubrication Schedule...
  • Page 18 3. Additional Maintenance Tips 1. Rest Periods o To prolong your treadmill’s life, turn off the power after 1.5 hours of continuous use. o Allow the treadmill to rest for 10 minutes before using it again. 2. Running Belt Tension o If the belt is too loose, it may slip during use.
  • Page 19 IX. EXPLODED DIAGRAM EXPLOSIVE DIAGRAM |...
  • Page 20 X. COMPLETE PARTS LIST Name Specification Qty. Name Specification Qty. Main frame assembly Allen wrench Magnetic ring Base assembly Silicon oil Left column assembly With cross handle S = 13, 14, 15 Right column assembly Bolt M8 * 65 Electronic watch frame as- sembly Bolt M8 * 45...
  • Page 21 Standard spring washer Lower controller Standard spring washer Power cord Flat Washer Class C Power cord buckle Internal serrated locking washer Overload protector Internal serrated locking Power switch washer Internal serrated locking Safety lock seat washer Rubber mat IP Rack Standard spring washer Nylon isolation pad Flat washer...
  • Page 22 XI. EXERCISE GUIDE PLEASE NOTE: Before beginning any exercise program, consult your physician. This is important especially if you are over the age of 45 or individuals with pre-existing health problems. The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the accuracy of heart rate readings.
  • Page 23 COOL DOWN Finish each workout with a light jog or walk for at least 1 minute. Then complete 5 to 10 minutes of stretching to cool down. This will increase the flexibility of your muscles and will help prevent post- exercise problems.
  • Page 24 Any claim against this warranty must be made through your original place of purchase. Proof of purchase is required before a warranty claim may be processed. If you have purchased this product from the Official Lifespan Fitness website, please visit https://lifespanfitness.com.au/warranty-form For support outside of warranty, if you wish to purchase replacement parts or request a repair or service, please visit https://lifespanfitness.com.au/warranty-form and fill in our Repair/Service...
  • Page 25 XIII. HAND PULSE TECHNOLOGY This product comes equipped with hand pulse sensors which are used to pick up tiny EKG/ECG signals that run through the body when your heart beats. These electrical EKG/ECG signals are very small and must be amplified 1000 times to make the signal viable for the computer to display your pulse. To ensure proper operation: •...
  • Page 28 WWW.L IF ESPAN F ITNE S S . COM . A U...
