HARDWARE IDENTIFICATION CHART

This chart is provided to help identify the hardware used in the assembly process. After unpacking the unit,
open the hardware bag and make sure that you have the following items:
3/16"
0 1/2
0 10 20
6
NOTE: Some of the hardware items listed may be attached to other parts.
1/4" 5/16"
1 1/2 2
30 40 50
8 10
Part No. and Description
32
34
35
36
38
42
43
3/8" 1/2"
1/2 3 1/2
60 70 80 90
12 Place washers, the end of bolts or screws on the
circles to check for the correct size. Use the small
scale to check the sizes of bolts and screws.
Bolt, Hex Head (M6 x 1 x 45mm)
Bolt, Hex Head (M8 x 1.25 x 50mm)
Nylock Nut (M6 x 1)
Nylock Nut (M8 x 1.25)
Washer (M8)
Large Washer (M6)
Bolt, Button Head (M6 x 1 x 8mm)
5
INCHES
4 1/2 5
100 110 120 130 140 150
MILLIMETERS
1/2 6
in.
mm.
Qty
2
2
2
2
4
2
2
