LED Indicators

NOTE: The Wireless and WPS LEDs are only available on the NB14WN
The front panel LED indicators are shown and explained below
LED Icon
Power
ADSL
Internet
Wireless
WPS
Ethernet
LED Color
Green
Green
Green
Green
Green
Green

Back Panel Connectors

The below table shows the function of each connector and switch of the NB14WN's back panel. The image illustrates the connectors.
Connector
POWER
ON/OFF
LAN1~4
ADSL
RESET
NOTE: The model shown is the NB14WN. The NB14 has no wireless antenna and only one LAN port
ADSL2+ Modem Router User Guide
6
Description
Lights up when powered ON.
Lights up when the router is connected via ADSL.
Lights up when connected to the Internet.
Lights up when specific Wireless connection is established, Blinks on WAN / LAN traffic and Blinks on Temporarily
overridden to LAN mode.
Lights up when Wi-Fi protected Set Up is being used
Lights up when the corresponding LAN port is being used
On
Ready
Connect to DSLAM
The device has a WAN IP address from ISP
WLAN Ready
N/A
Ethernet Connected
Flash
Waiting for device ready
Disconnect to DSLAM
Transmit / Receive Data
Transmit / Receive Data
Start WPS peer within 2 minutes
Transmit / Receive Data
Description
Connects to your NB14WN's 12VAC power adaptor
Power Switch
RJ-45 Jack (Ethernet Cable) connection to your PC or switch
Connects to your ADSL2+ line – for ADSL2+ Line input
Reset button, RESET the NB14WN to its default settings
Off
Power Off
N/A
N/A
WLAN Off
WPS Idle
Ethernet Disconnected
YML14WN
