PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
OWNER'S MANUAL
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WHAT TO DO IF YOU SMELL GAS
• Open windows/extinguish any open
flame.
• Do not try to light any appliance.
• Do not touch any electrical switch
or use any phone in your building.
• Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas
supplier, call the fire department.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any other appliance.
WARNING:
If the information in this manual is not followed
exactly, a fire or explosion may result causing property damage,
personal injury or loss of life. Installation and service must be
performed by a qualified installer, service agency or the gas supplier.
Massachusetts installations (Warning): This product must be installed by a licensed plumber
or gas fitter when installed within the Commonwealth of Massachusetts. Other Massachusetts
code requirements: Flexible connector must not be longer than 36in., a shut off valve must
be installed; only direct vent sealed combustion products are approved for bedrooms/
bathrooms. A carbon monoxide detector is required in all rooms containing gas fired direct
vent appliances. The fireplace damper must be removed or welded in the open position prior
to installation of a fireplace insert.
FOCUS
B Y : S H E R W O O D I N D U S T R I E S L T D
This appliance is
only for use with the
type of gas indicated
on the rating plate.
This appliance is not
convertible for use
with other gases,
unless a certified kit
is used.
EG31-118
