OWNER'S MANUAL
SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
FOR YOUR SAFETY: Do not store
or use gasoline or other flammable
vapours and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Open windows/extinguish any
open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch
or use any phone in your building.
• Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas
supplier, call the fire department.
INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
WARNING:
If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life. Installation and service must
be performed by a qualified installer, service agency or the gas supplier.
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas fitter when installed within the Commonwealth of Massachusetts. Other
Massachusetts code requirements: Flexible connector must not be longer than 36in., a
shut off valve must be installed; only direct vent sealed combustion products are approved
for bedrooms/bathrooms. A carbon monoxide detector is required in all rooms containing
gas fired direct vent appliances. The fireplace damper must be removed or welded in the
open position prior to installation of a fireplace insert.
Version Française: www.enviro.com/fr.html
FOCUS
B Y : S H E R W O O D I N D U S T R I E S L T D
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
EG31-118
