13 Threshold Control - controls the signal level at which the compressor/limiter becomes active.
Master Mic/Line Switch - selects master output as either mic level (-50 dBu) or line level
14
(0 dBu).
15
Ratio Control - controls the amount of compression of the signal above the threshold.
Phantom Power Switch - when activated, supplies +30VDC power (for condensor
16
microphones) to all channels with the mic/line switch set to mic position.
8002MCB-FP Rear Panel
A
Ground Lift Jumper - access to ground lift jumper J19.
AC Power Connector - mixer power supply input; accepts a 4-pin DIN connection from
B
an 18VCT 1.5 amp transformer.
C Auxiliary Bus Output Connector - XLR or Phoenix balanced/unbalanced, line-level connector.
D Main Bus Output Connector - XLR or Phoenix balanced/unbalanced, line-level connector.
Auxiliary Input Connector - balanced, buffered, uncontrolled, line-level XLR or Phoenix jack
for an additional (ninth) input connection directly to the summing buses as selected by the
E
internal jumpers.
F Main Input Connector - XLR or Phoenix balanced/unbalanced connector.
