- Page 1 VC Series Mic/Line Mixers 4001 VC 4001 VCX User Manual 8001 VC 8001 VCX...
-
Page 2: Warranty
If a unit which is out of warranty needs repair, the dealer must pay for shipping, replacement parts, and a fixed $100/hr labor fee. Normal Intelix credit terms apply to billable repairs. If a unit is returned and found to work according to factory specifications, a standard $100 service fee is billed regardless of warranty status. -
Page 3: Table Of Contents
Intelix VC Series Mic/Line Mixer User Manual Table of Contents Warranty....................... 2 Introduction......................6 1.0 Introduction....................... 6 1.1 Safety Instructions...................... 6 1.2 Maintenance Guidelines....................6 1.3 Quick Start for the VC Series Mixer................7 1.3.1 Unpack and connect..................7 1.3.2 Power and setup.................. - Page 4 Intelix VC Series Mic/Line Mixer User Manual Special Features Activation................6.0 Special Features Activation..................External Control....................7.0 External Control...................... 7.1 The Connectors....................... 7.2 Mixer Expansion through Linking................7.3 DC Control......................7.3.1 Remote volume control................7.3.2 Connecting a remote volume control............
-
Page 5: Intelix
Intelix VC Series Mic/Line Mixer User Manual Troubleshooting Tips..................... 34 Technical Specifications..................36 Mixer Block Diagram................... 37 Glossary......................... 38 intelix... -
Page 6: Introduction
Intelix VC Series Mic/Line Mixer User Manual 1.0 Introduction This manual describes the components and operation of the Intelix VC Series line of mic/line mixers. As with all Intelix products, the VC Series ensures the highest quality audio signal production and control through easy-to-use fea- tures. -
Page 7: Quick Start For The Vc Series Mixer
Intelix VC Series Mic/Line Mixer User Manual Ensure adequate ventilation is provided on the sides, ambient air temperature does not exceed 72 degrees F, and an open rack space is left above and below the units. To minimize hum in the system, avoid placing cables near EMF-producing devices such as electrical motors, fluorescent lights, AC power lines, and SCR dimmers. -
Page 8: Panel Descriptions
Intelix VC Series Mic/Line Mixer User Manual 2.0 Panel Descriptions VC and VCX Front Panel Signal Present LED (on VCX models exclusively) - if lit (green), indicates at least a -10 dB input signal. Channel Volume Knob (four on 4001 models, eight on 8001 models) - controls volume on the input channel. - Page 9 Intelix VC Series Mic/Line Mixer User Manual VC and VCX Rear Panel Ground Lift Jumper - jumper J4; connects chassis to an electric ground. AC Power Connector - mixer power supply input; accepts a 4-pin DIN connection from an 18VCT 1.5 amp transformer.
-
Page 10: Installation And Operation
First, remove the mixer from its box, inspecting the unit for shipping damage. If there is obvious physical damage, contact Intelix immediately before proceeding with the installation. Next, set all volume control knobs on the mixer to zero. Also, set all amplifier volume con- trols to zero. -
Page 11: Recommended Input Wiring Methods
3.2 Recommended Input Wiring Methods The following are the recommended methods for connecting sources to the Intelix VC Series mixer. The mixer input is always balanced. From the following drawings, choose the wiring method for your input device (either balanced or unbalanced). -
Page 12: Channel 4 (On 4001 Models) Or 8 (On 8001 Models)
Intelix VC Series Mic/Line Mixer User Manual 3.3 Channel 4 or 8 (on 4001 models) (on 8001 models This channel accepts two types of inputs. Two inputs may be connected to the channel at the same time, but only one at a time may be mixed. -
Page 13: Gain Structure
In order to maintain the highest level of S/N in the mixer, the audio signals are never brought through the front panel controls of the Intelix mixer. Instead, each front panel pot controls a Voltage Controlled Attenuator (VCA), which controls the associated amplification stage. The channel VCAs do not control an amplifier, but are attenuation only devices which determine the amount of each channel’s contribution to the summing bus. -
Page 14: Gain Structure Illustration
Intelix VC Series Mic/Line Mixer User Manual 4.1 Gain Structure Illustration intelix... -
Page 15: Gain Setup On Standard Vc Models
Intelix VC Series Mic/Line Mixer User Manual 4.2 Gain Setup on Standard VC Models Preliminary steps: 1. Ensure the audio sources are connected to the channel inputs on the VC Series mixer. 2. Ensure the VC Series mixer’s output is connected to an external amplifier. -
Page 16: Mixer Fine Tuning
Intelix VC Series Mic/Line Mixer User Manual 5.0 Mixer Fine Tuning 5.1 Fine Tuning on both VC and VCX Models 5.1.1 Low cut switch To remove excessive bass response from an individual channel, press that channel’s low cut switch. The low cut feature helps eliminate low frequency noise (signals of 150 Hz or lower;... -
Page 17: Select Bar Graph Readout
Intelix VC Series Mic/Line Mixer User Manual If during ordinary use one or more inputs occasionally exceed the maximum input levels set up during the set up procedure (i.e., the red (+12 dB) LED on the bar graph meter occasion- ally lights), press the Output Limiter Switch to the on position. -
Page 18: Special Features Activation
Intelix VC Series Mic/Line Mixer User Manual 6.0 Special Features Activation Intelix VC Series mixers have several special built-in features which make the remote control, ducking, and muting of both the individual channel inputs and the master output easy to activate and simple to change. -
Page 19: External Control
Intelix VC Series Mic/Line Mixer User Manual 7.0 External Control 7.1 The Connectors All external controls and signal sources are attached via the rear panel DB25 Control Pin Connector. Note: Individual control of channels 1, 3, 5, and 7 on 8001 models requires the installation of the optional 25 EXT card. -
Page 20: Mixer Expansion Through Linking
Intelix VC Series Mic/Line Mixer User Manual 7.2 Mixer Expansion through Linking Intelix VC mixers can be simply linked to provide a wider mixer bus. For example linking two VC 8 channel mixers results in a 16 channel mixer. Although an indefinite number of mixers can be linked in this way, Intelix recommends that you link no more than three mixers because of the accumulation of noise. -
Page 21: Dc Control
Intelix VC Series Mic/Line Mixer User Manual 7.3 DC Control VC Series mixers are configurable for external control of individual channel volume by a DC voltage. Up to 4 input channels and the master output volume can be connected to remote controls simultaneously. -
Page 22: Wiring An External Combination Mute Switch And Volume Control
Intelix VC Series Mic/Line Mixer User Manual 1) Connect a wire from one side of the switch to the wiper pin of the channel to be muted. 2) Connect a wire from the other side of the switch to a ground pin on the DB25 connector. -
Page 23: Setting Channel Duck Details
Intelix VC Series Mic/Line Mixer User Manual Four main components must be adjusted for automatic ducking: 1) Duck Activate Channel Pins (P13) select duck triggering channels. 2) Duck Output Channel Pins (P11, P19) allow each non trigger channel to be ducked or unducked. -
Page 24: Ducked And No Duck Channel Selection
Intelix VC Series Mic/Line Mixer User Manual Channel will not Channel will be be ducked when ducked when jumper is placed jumper is placed in position A. in position B. 7.4.1.2 Ducked and no duck channel selection To select a channel to be ducked, place a jumper between the two pins for that channel on P11 (as shown in position B). -
Page 25: Ducking Amount
Intelix VC Series Mic/Line Mixer User Manual 7.4.2.1 Ducking amount The amount that the lower priority channels will be ducked can be varied from 0 dB to - 100dB. The factory setting is -10dB. All low priority channels are ducked by the same amount. -
Page 26: Other Ducking Techniques
Intelix VC Series Mic/Line Mixer User Manual 7.4.3 Other ducking techniques 7.4.3.1 Remote (manual) ducking The ducking circuitry can be activated with an external switch, so that even if no signal is present on any of the high priority channels, low priority channels will be ducked when the switch is depressed. -
Page 27: Audio Inserting And Patching
Intelix VC Series Mic/Line Mixer User Manual 8.0 Audio Inserting and Patching The VC series mixer provides the ability to both patch and link the mixer’s audio output. Tapping allows the output of the mixer to be routed to an external device, e.g. -
Page 28: Master Output Insert Patching
Intelix VC Series Mic/Line Mixer User Manual 8.2 Master Output Insert Patching To use the patching feature of the VC mixer follow these directions: 1) Remove the top of the mixer chassis, and remove jumper J1. For location of J1 see Section 7.4. - Page 29 Intelix VC Series Mic/Line Mixer User Manual This drawing shows how to connect a This drawing shows how to connect an balanced output device to the link input of unbalanced output device to the link input the VC mixer. Jumper J1 depends on of the VC mixer.
-
Page 30: The 25Ext Card
Intelix VC Series Mic/Line Mixer User Manual 9.0 The 25EXT Card The 25EXT card is a standard part of all VCX model mixers, and an option for all VC models. If you have a VC mixer follow the installation instructions below. -
Page 31: Remote Control With The 25Ext
Intelix VC Series Mic/Line Mixer User Manual 9.2 Remote Control with the 25EXT The use of the 25EXT to remotely control the volume of individual channels is identical to the process for the standard VC mixer, except for the pinout of the connec- tor. -
Page 32: Individual Channel Patching
Intelix VC Series Mic/Line Mixer User Manual 9.3 Individual Channel Patching The use of the 25EXT card enables audio insert patching into each input channel. With this feature each channel can: 1) send its output to another device for processing and route the processed signal back to the mixer for inclusion in the master output patching. -
Page 33: Mixer Power Connections
Intelix VC Series Mic/Line Mixer User Manual 10.0 Mixer Power Connections 10.1 AC Power Connection The manufacturer supplies a 16 VAC Center-Tapped, 21VA or 18 Volt, 1.5 Amp center-tapped transformer, depending on model (see technical specifications for details). Shown at right is the end view of the power supply’s power cord connector. -
Page 34: Troubleshooting Tips
Intelix VC Series Mic/Line Mixer User Manual 11.0 Troubleshooting Tips NO POWER Check the connections between the mixer and the power supply and the external AC power supply. Check the wall outlet. NO SOUND Make sure the mic/line switch is in the proper position. (This is the most likely cause.) - Page 35 Intelix VC Series Mic/Line Mixer User Manual DUCKING: The system is ducking when it shouldn’t Check that the pins which select the higher-priority channels are correctly jumpered on P13. Check the channel input levels. The threshold of one or more of the higher- priority (“Duck Activate”) channels may be too low.
-
Page 36: Technical Specifications
12.0 Technical Specifications Intelix VC Series mic/line mixers come in two models: the standard VC in 4 or 8-channel, featuring a compressor/limiter and low cut filter; and the enhanced VCX in 4 or 8-channel, featuring a compressor/limiter, low cut filter, APHEX Aural Exciters, priority channel autoducking, individual channel signal present and clip LEDs, master output VU metering, and an insert patch or direct out for all channels. -
Page 37: Mixer Block Diagram
Intelix VC Series Mic/Line Mixer User Manual 12.1 Mixer Block Diagram Front Panel Controls and Indicators Clip Signal Low Cut Front Panel Front Panel Aphex In / Out Limit In / Out Indicator Present In / Out Input Volume Master Volume... -
Page 38: Glossary
Intelix VC Series Mic/Line Mixer User Manual 13.0 Glossary 25 EXT - Accessory card that provides access to input channel patch points. For 8-channel models, provides remote volume control of channels 1, 3, 5, and 7. Aphex® Aural Exciter® - Pseudoacoustical process that increases signal intelligibility by adding supplementary harmonic information. - Page 39 Intelix VC Series Mic/Line Mixer User Manual Signal Clip LED - On the VCX mixers, the indicator that lights (red) when the input signal to a channel is greater than +18 dB. Signal Present LED - On the VCX mixers, the indicator that lights (green) when the input signal to a channel is at least -10 dB.
- Page 40 Intelix VC Series Mic/Line Mixer User Manual intelix...
