INSTALLATION AND
OPERATION MANUAL
MASTER SERIES
INFRA-RED & CERAMIC
BROILER
FOR YOUR SAFETY:
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS OR
LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER
IMPROPER INSTALLATION, ADJUSTMENT,
ALTERATION, SERVICE OR MAINTENANCE
CAN CAUSE PROPERTY DAMAGE, INJURY,
OR DEATH. READ THE INSTALLATION,
OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR
SERVICING THIS EQUIPMENT
Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent
using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been
improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation
instructions provided with the product, or any product that has its serial number defaced, obliterated or removed,
or which has been modified or repaired using unauthorized parts or by unauthorized service agents.
For a list of authorized service agents, please refer to the Garland web site at http://www.garland-group.com.
The information contained herein, (including design and parts specifications), may be superseded and is subject
to change without notice.
GARLAND COMMERCIAL INDUSTRIES
185 East South Street
Freeland, Pennsylvania 18224
Phone: (570) 636-1000
Fax: (570) 636-3903
Part # 4515576 Rev 1 (01/21/10)
Part # 4515576 Rev 1 (01/21/10)
APPLIANCE
WARNING:
PLEASE READ ALL SECTIONS OF THIS MANUAL
AND RETAIN FOR FUTURE REFERENCE.
THIS PRODUCT HAS BEEN CERTIFIED AS
COMMERCIAL COOKING EQUIPMENT AND
MUST BE INSTALLED BY PROFESSIONAL
PERSONNEL AS SPECIFIED.
IN THE COMMONWEALTH OF MASSACHUSETTS
THIS PRODUCT MUST BE INSTALLED BY A
LICENSED PLUMBER OR GAS FITTER.
For Your Safety:
Post in a prominent location, instructions to be
followed in the event the user smells gas. This
information shall be obtained by consulting
your local gas supplier.
GARLAND COMMERCIAL RANGES, LTD.
1177 Kamato Road, Mississauga, Ontario L4W 1X4
CANADA
Phone: 905-624-0260
Fax: 905-624-5669
© 2004 Garland Commercial Industries, Inc.
Page 1
Advertisement
Chapters
Table of Contents
Related Manuals for Garland M60XR
Summary of Contents for Garland M60XR
- Page 1 Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation instructions provided with the product, or any product that has its serial number defaced, obliterated or removed, or which has been modified or repaired using unauthorized parts or by unauthorized service agents.
-
Page 2: Important Information
IMPORTANT INFORMATION WARNING: This product contains chemicals known to the state of California to cause cancer and/or birth defects or other reproductive harm. Installation and servicing of this product could expose you to airborne particles of glass wool/ceramic fibers. Inhalation of airborne particles of glass wool/ceramic fibers is known to the state of California to cause cancer. -
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT INFORMATION......... . 2 SPECIFICATIONS . -
Page 4: Specifications
MANIFOLD Model Broiler Burner Base PRESSURE OPERATING PRESSURE Number Natural Gas: 7” w.c. Natural Gas: 6” w.c. M60XR Cast Iron Burner With Standard Oven Propane: 11” w.c. Propane: 10” w.c. Ceramic Tile M60XRC Cast Iron Burner With Convection Oven Electrical Supply... -
Page 5: General Information
2. The wires for retaining the burners and other packing 5. Garland/U.S. Range products are not approved or material must be removed from units. Any protective authorized for home or residential use, but are intended material covering stainless steel parts must also be for commercial applications only. -
Page 6: Installation
INSTALLATION Siting Where it is not practical to do this, an automatic isolation valve system shall be fitted which can be operated from a The floor on which the appliance is to be sited must be readily accessible position near to the exit. capable of adequately supporting the weight of the At locations where the manual isolation valve is fitted or appliance and any ancillary equipment. -
Page 7: Appliances Equipped With Casters
INSTALLATION Continued Appliances Equipped With Casters 1. Be sure that all valves and thermostats are in the “OFF” position. 1. The installation shall be made with a connector that 2. Turn on the main gas supply valve. Light all broiler pilots. complies with the Standard for Connectors for Moveable Gas Appliances, ANSI Z21.69/CSA 6.16, Addenda Z21.69B- 3. - Page 8 INSTALLATION Continued 1. Place the thermocouple of the test instrument or reliable Indicator Mark mercury thermometer in the center of the oven. Calibration By-pass Flame Plate 2. Turn the oven temperature control knob to 400°F, (204°C), Adjuster and allow the oven to cycle at least three times. Calibration Lock Screws Dial...
-
Page 9: Operation
10-15 seconds. Infra-Red Burners -M100XM, M110XM 5. The haze will disappear and the ceramics will glow red. The GARLAND® Infra-Red Broiler is a direct radiant heavy Shut-Down: duty gas broiler utilizing four (4) extremely efficient gas burners in each broiling section. -
Page 10: Ovens
OPERATION Continued CAUTION: Should burner ignition fail within 5 seconds, Convection Ovens (RC) turn the burner valve off and repeat steps 1 through 5. If Lighting: ignition continues to fail, consult your factory authorized service agency. Same as standard oven. Ovens Start-Up: Standard Ovens... -
Page 11: Product Application
PRODUCT APPLICATION Broiler It is suggested that all products be dipped in salt-free oil before broiling to facilitate browning and to aid in The following information is intended for use as a guide. preventing the product from sticking to the broiler rack. There are many variables that will effect the operation. -
Page 12: Care & Cleaning
PRODUCT APPLICATION Continued Center the load on the oven racks to allow for proper heat When rethermalizing frozen products, preheat the oven 50°F circulation around the sides. The oven will hold three, 18” x (10°C), higher than the cooking temperature to compensate 26”... -
Page 13: M110Xm
CARE & CLEANING Continued Remove and clean the grid rack inserts and grease drip chute Instructions For Removal Of Grid Rack & daily. Pull the grid rack forward and lift the grease rack insert Grid Rack Frame out of the frame. Remove the grease drip chute by pulling it forward out of the rack frame guides. -
Page 14: Wiring Diagram
WIRING DIAGRAM Page 14 Part # 4515576 Rev 1 (01/21/10) - Page 15 Part # 4515576 Rev 1 (01/21/10) Page 15...
-
Page 18: Câblage De Schéma
Page (01/21/10) 4515576 Part CÂBLAGE SCHÉMA... - Page 19 (01/21/10) 4515576 Part Page service professionnel périodiquement nettoyés être doivent infrarouge à brûleurs élevées. températures résistant toxique roulements pour lubrifi sans végétale l’huile avec és lubrifi être doivent secs, être semblent lavés été rouleaux à roulements rouleaux. à roulements autour surtout sécurité.
-
Page 20: Grille
Page (01/21/10) 4515576 Part lave-vaisselle. dans lavé bien vaisselle à lavage produit avec main à nettoyé être peut ltre crémaillère. avant plaque par-dessus grille chaque l’utilisation. fonction jours, deux tous jours l’avant soulevant grilles crémaillères Retirer tous nettoyé retiré être doit M110XM l’appareil... -
Page 21: Convection À Fours
(01/21/10) 4515576 Part Page aliments. avec contact être pouvant surfaces produits tels utiliser surface. cireux huileux laissent commerce dans sèche. nettoyée zone disponibles produits nombreux existe extérieures, avant doux torchon avec sécher désinfectante solution surfaces digitales empreintes supprimer Pour dans trempée éponge avec... -
Page 22: Produit Du Applications
Page (01/21/10) 4515576 Part l’épaisseur. augmenter d’en cuisson avant etc. plie, sole, carrelet, lets replier recommandé (25) poisson Darne (13) poisson Darne *Poisson grille basse position brûleur- (Réglage Poisson (51) double Côtelette (25) côtes Carré, Agneau (13) haché Bifteck (19) Entrecôte (51) Surlonge... -
Page 23: (Rc) Convections À Fours
(01/21/10) 4515576 Part Page CHAUD. four quand cuisson pendant ») (« d’arrêt position être jamais devrait convection à four moteur Remarque minimum. minutes pendant fonctionne ventilateur façon cette refroidissement. position l’interrupteur placer gauche. à “Allumage” ouverte four porte laisser nitif, défi arrêt avant... -
Page 24: M110Xm -M100Xm, Infrarouge À Brûleurs
à brûleurs quatre rouge. devient céramique disparaît halo à grâce intensif l’usage à destinée directe radiante chaleur à à rôtissoire GARLAND® infrarouge à rôtissoire secondes. 10-15 pendant céramique surface M110XM -M100XM, infrarouge à Brûleurs couvre bleue amme établi, l’allumage fois canalisation d’alimentation... -
Page 25: Fdo Robuste Four De Commande
(01/21/10) 4515576 Part Page brûleur. longueur toute couvriront dérivation ammes réglées, correctement fois possible. stable plus basse amme d’obtenir brûleur amme diminuer pour inverse sens dans augmenter pour montre d’une aiguilles letés. été trous d’autres dans sens dans dérivation amme réglage déplacées être... -
Page 26: Réglages
Page (01/21/10) 4515576 Part nouveau. essayer minutes attendre brûleur, robinet fermer robinet, l’ouverture après secondes délai dans ferait l’allumage où Dans ouvert. robinet dont brûleurs tous l’allumage inégal. compenser niveau l’appareil vérifi l’utilisateur responsabilité coupée. mettre pour réglés encore être peuvent pieds sera... -
Page 27: L'installation Sur Remarques
(01/21/10) 4515576 Part Page d’eau. colonne dépassant pression éventuelle chute l’appareil. avec l’appareil alimenteront existants canalisation robinet entre installé être doit déconnexion compteur s’assurer pression vérifi moyen autre tout union raccord nettoyage. locale compagnie à demander additionnel, d’entretien intervention toute lors l’appareil isoler... -
Page 28: Générales Informations
Page (01/21/10) 4515576 Part échéant. locaux codes CSA-149.1 conforme être doit l’installation Canada, cace. effi sécuritaire fonctionnement assurer pour local code et/ou édition dernière ANSI/NFPA Code Electrical National édition dernière NFPA édition, dernière 223.1- ANSI Code Fuel National conforme être doit L’installation destination. -
Page 29: Dégagements
(152mm) 6” (152mm) 6” M60XS Céramique Tuile 80,000 (152mm) 6” (152mm) 6” M60XRC Avec Fonte Brûleur (152mm) 6” (152mm) 6” M60XR taille BTU/h Brûleur Orifi Débit modèle Arrière Côtés Numéro Propane Installation Dégagements 40,000 Four 70,000 Infrarouge Dégagements Céramique Tuile... - Page 30 Page (01/21/10) 4515576 Part CÂBLAGE. SCHÉMA ........
-
Page 31: Importantes Informations
(01/21/10) 4515576 Part Page combustibles. produits stocker dégagés l’appareil abords Maintenir reproductifs. problèmes d’autres congénitales malformations causer pouvant comme Californie l’état reconnue carbone monoxyde L’inhalation réglage. mauvais carbone monoxyde exposer vous peut produit L’utilisation cancer. causant comme Californie l’état reconnue céramiques fibres verre... - Page 32 Page (01/21/10) 4515576 Part Inc. Industries, Commercial Garland 2004 © (01/21/10) 4515576 nº Pièce 905-624-5669 Télécopieur 636-3903 (570) Télécopieur 905-624-0260 Téléphone 636-1000 (570) Téléphone CANADA 18224 Pennsylvanie Freeland, Ontario Mississauga, Road, Kamato 1177 Street South East LTD. RANGES, COMMERCIAL GARLAND...
