Signal
Pin No.
VDD_PLL
SAVDD
SAVSS
GAVSS
15, 30, 81,
3VDD
115, 131,
48, 67, 89,
5VDD
141, 195
11, 25, 39,
58, 76, 101,
VSS
108, 124,
150, 172,
I/O Type
186
1
5
204
160
181
PLL power (3.3V).
Analog power for scan ADC and general ADC (3.3V).
Scan ADC ground.
General ADC ground
3.3V internal power.
Externally connected to the 3.3V regulator.
5V I/O power.
Externally connected to the VCC board plane.
System ground.
Externally connected to the ground board plane.
