Muratec F-110 Field Engineering Manual page 107

Shield Engine Unit Assembly Parts List
No.
0 ELA HOU-SHIELD ENGINE
1 CABLE-FLAT
2 CBF HARNESS-LSU
3 CBF HARNESS-MAIN-HVPS
4 CBF HARNESS-MAIN/HOOK
5 CBF HARNESS-MODULA 2
6 CBF HARNESS
7 IPR-SHIELD ENGINE
8 IPR-SHILED SMPS
9 MEC-GUIDE STAKE ASS'Y
10 PBA MAIN-MAIN
11 ELA M/MEDIO AUD-SPEAKER
12 WASHER-E.T
13 CBF HARNESS-THERMISTOR
S2 SCREW-MACHINE
S8 SCREW-TAPTITE
S9 SCREW-TAPTITE
Description
O : Service available X : Service not available
SEC.Code Q'ty
JC96-02087D 1
J3809-001161 1
JC39-00043A 1
JC39-00109A 1
JC39-00174A 1
JC39-00175A 1
JC39-40022A 1
JC70-00200A 1
JC70-00263A 1
JC75-00087A 2
JC92-01308C 1
JC96-01607A 1
6031-000120 1
JC39-00045A 1
6001-000568 2
6003-000221 1
6003-000264 11
Exploded View and Parts List
SA Remark
X
O
X
X
X
X
X INLET
X
X
X
O
O
X
X
X
X
X
6-5
