For Optional Direct DC Power
Screw-on the DC power cable to the power connector on the modem.
Then attach the two wires at the other end of the DC power cable to a DC fuse/terminal block.
Connect the red wire to the "+" (positive) terminal and the black wire to the "–" (negative) terminal. Be sure
the GND connection is correct.
Warning:
Over-voltage protection is provided on the device. To ensure complete protection, you may want to add
additional filtering to the DC input.
Note:
For automotive application: according to the type of application, you can use permanent "+" or key-
switched "+" source. Connect the power supply to its source (for example, in a mobile situation, to the
vehicle's DC fuse/terminal block).
Multi-Tech Systems, Inc. MultiModem Cell User Guide
Chapter 2 – Activation and Installation
15
