12. The Console (5) can be operated with four 1.5V
"D" batteries; alkaline batteries are recommend-
ed. IMPORTANT: If the elliptical exerciser
has been exposed to cold temperatures,
allow it to warm to room temperature before
inserting batteries into the Console. If you
do not do this, the console displays or other
electronic components may become dam-
aged. Press the tab on the battery cover, and
remove the battery cover. Next, insert four bat-
teries into the Console. Make sure that the
batteries are oriented as shown by the dia-
grams inside the battery compartment. Then,
reattach the battery cover to the Console.
Note: The Console (5) can also be operated
with an optional power supply instead of batter-
ies. To purchase a power supply, call the
telephone number on the front cover of this
manual. Plug one end of the power supply into
the jack on the Console. Plug the other end of
the power supply into an appropriate outlet that
is properly installed in accordance with all local
codes and ordinances.
13. Tip: Be careful not to pinch the wire har-
nesses during this step. While another person
holds the Console (5) near the Upright (3), con-
nect the wire harness on the Console to the
Upper Wire Harness (48). Insert the excess
wire harness into the Upright. Next, attach the
Console to the Upright with four M4 x 16mm
Round Head Screws (101).
14. Make sure that all parts of the elliptical exerciser are properly tightened. Note: Some hardware may be
left over after assembly is completed. To protect the floor or carpet from damage, place a mat under the
elliptical exerciser.
12
Batteries
5
13
48
11
Batteries
Battery
Cover
Avoid pinching the
wire harnesses
during this step
5
Console Wire
3
101
