8.0 Specifications

PARAMETER
Max Input Level
Min Input Level
Bandwidth
Gain
Impedance
Return Loss
Return Loss
Distortion*
Isolation
Isolation
Switching time
Phase Noise*
(Referred to the Input)
Temperature-delay
Coefficient
*All tests done at 5 MHz and +13 dBm input unless otherwise specified.
Rackmount chassis
Storage temperature
Operation environment
Humidity
Page 20
CONDITIONS
1 dB compression
no fault
+/- 1 dB
@ 5 MHz
output
input(S )
11
output(S )
22
+13 dBm
output to output
output to input
input1 to input2
Autoswitch mode
1 Hz
10 Hz
100 Hz
>10 kHz
0 - 50 ºC
1U H, 19" W, 14" D
-10 to +75 ºC
0 to +50 ºC
5% to 95% non-condensing
MIN TYP
17 18
7 8
1-50 0.5-65
- 0
- 50
- -25
- -35
- -45
130 140
140 145
100 110
- 0.5
- -147
- -157
- -167
- -171
- 1.5
MAX UNITS
- dBm
- dBm
- MHz
+/- 0.5 dB
- Ohms
-20 dB
-30 dB
-42 dBc
- dB
dB
- dB
1 us
-145 dBc/Hz
-155
-166
-170
3 ps/ºC
