- Page 1 PECTRA YNAMICS, ERFORMANCE ISTRIBUTION MPLIFIER HPDA-100RM-A PERATING ANUAL PECTRA YNAMICS, NC • 1849 Cherry St. Unit 2. • Louisville, CO 80027 Phone: (303) 665-1852 • Fax: (303) 604-6088 www.spectradynamics.com...
- Page 3 Description The HPDA-100RM-A is a high performance distribution and isolation amplifier. It contains one module that provides five unity gain outputs. Typical cross channel isolation and reverse isolation is typically greater than 100 dB. The phase noise of the modules is exceptionally low, typically –145 dBc/Hz @ Fourier frequency of 1 Hz and –173 dBc/Hz @ Fourier frequency greater than 10 kHz.
-
Page 4: Safety And Preparation For Use
Line Voltage This instrument may be setup to operate on 100-120 or 220-240 VAC and a line frequency of 50 to 60 Hz. The setup voltage for this HPDA-100RM-A is specified on page 4. Fuse A 2.0 Ampere 250V slow-blow fuse is used for 100-120 VAC operation. -
Page 5: The Front Panel
The LED labeled POWER is on when power is applied to unit and the unit is operating properly. Signal LED The LED labeled SIGNAL will turn on when you apply an input signal to the SMA input connector greater than +7 dBm. Copyright © SpectraDynamics, Inc. 2010... -
Page 6: The Back Panel
The Back Panel AC POWER ENTRY MODULE The HPDA-100RM-A is configured to operate on: 100-120 VAC 220-240 VAC SMA INPUT The signal to be distributed should be connected to the SMA jack labeled INPUT. SMA OUTPUTS The five outputs of each amplifier module are DC isolated from the chassis ground to prevent ground loops. -
Page 7: Operation
Plug the unit into an appropriate power outlet. The green LED on the front panel labeled POWER will turn on. Attach the signal to be distributed to the SMA input connector on the front panel. Any HPDA-100RM-A output may be used to drive the input of another distribution module. -
Page 8: Specifications
Output to input Phase Noise 10 Hz -158 -155 dBc/Hz 100 Hz -165 -162 1 kHz -171 -168 10 kHz -174 -171 All tests done at 100 MHz and +13 dBm input unless otherwise specified Copyright © SpectraDynamics, Inc. 2010... -
Page 9: Warranty
This warranty shall be in effect for one (1) year from the date a HPDA-100RM-A is sold by SDI. SDI makes no other warranty, express or implied, and makes no warranty of the fitness for any particular purpose. SDI’s obligation under this warranty shall not include any transportation charges or costs of installation or any liability for direct, indirect, or consequential damages or delay. - Page 10 HPDA-100RM-A:1I-5O/R02...
