6.0 Operation
Bit 2
Bit 1
LSB Bit 0
signal
MSB Bit 12
Bit 11
Bit 10
LSB Bit 0—9
[control] [signal]<cr>
For example:
input: *SR<cr>
output: 22 1<cr>
The command *SR is sent to the standard telnet port 23 at the ip address of the HPDA-
15RMi-S. The instrument responds with string shown above where the control status is 22
and the signal status is 1.
control = 23 = 16 + 0 + 4 + 2 + 1 = [1] [0] [1] [1] [1]
signal = 0 = 0 + 0 + 0 + 0 + 0 + 0 +0 + 0 + 0 = [0] [0] [0] [0] [0] [0] [0] [0] [1]
The control status returned by the instrument means:
DC power is not present.
The instrument is in local mode of operation.
Autoswitch mode is enabled
Input 2 was selected as the input channel
Input 2 is the currently selected active channel
The signal status means:
1 - Autoswitch mode enabled
0 - Autoswitch mode disabled
1 - Channel select switch position 2
0 - Channel select switch position 1
1 - Active channel is INPUT 2
0 - Active channel is INPUT 1
1 - AC Power fault
0 - AC Power OK
1 - INPUT 2 signal fault
0 - INPUT 2 signal OK
1 - INPUT 1 signal fault
0 - INPUT 1 signal OK
1 - Output channel signal fault
0 - Output channel signal ok
