6.0 Operation
AC power is OK
INPUT 2 signal is OK
INPUT 1 signal is OK
Outputs 10 - 2 signal are OK
Output 1 signal fault
*CL<cr> Clear latched status command.
The *CL command clears the latched control and signal status registers. This command
may be used to clear a fault condition after the fault has been corrected. The instrument
does not return any information after this command.
For example:
input: *CL<cr>
*ID<cr> Request identification command.
The *ID command returns the model number and serial number of the instrument. This
command may be used to verify the identity of the device that is being controlled. The
instrument will respond with the command the model number and serial number.
ModelNumber SerialNumber<cr>
For example:
input: *ID<cr>
output:HPDA-15RMi-S 13HP021-01<cr>
*RF<cr> Read Input signal levels command.
The *RF command returns a string with the signal levels for INPUT 1 and INPUT 2 in dBm
units. The signal levels are approximate and the accuracy is +/- 1 dB in the range of –
10dBm to +15 dBm.
For example:
input: *RF<cr>
output:RF1:13.09, RF2:10.20<cr>
*PWR<cr> Read the internal voltage levels of the instrument command.
The *PWR command returns a string with the internal voltage levels of the instrument and
may be used to monitor both the power supply derived from the AC mains as well as the
power from the DC battery backup system. Used to read the internal voltage levels. The
DC values will not be present unless the DC backup power is supplied to the instrument.
Normal values are in the range of 13.8 - 14.8V.
