- Page 1 PECTRADYNAMICS, ERFORMANCE ISTRIBUTION MPLIFIER HPDA-15RM/A PERATING ANUAL PECTRADYNAMICS, NC • 1849 Cherry St. Unit 2. • Louisville, CO 80027 Phone: (303) 665-1852 • Fax: (303) 604-6088...
- Page 2 HPDA-15RM/A Description The HPDA-15RM/A is a high performance distribution and isolation amplifier. It contains a high performance distribution module that provides 5 unity gain outputs. Typical cross channel isolation is 125 dB and reverse isolation is typically greater than 135 dB. The phase noise of the module is exceptionally low, typically –150 dBc/Hz @ Fourier frequency of 1 Hz and –173 dBc/Hz @ Fourier frequency greater than 10 kHz.
-
Page 3: Safety And Preparation For Use
To operate the unit, locate the AC power entry connector on the rear panel and connect the power cable. When power is applied to the unit, a red led located on the front panel, labeled “on”, should light up. Copyright © SpectraDynamics, Inc. 1999... -
Page 4: The Front Panel
Make sure that the amplifier ground does not float to a potential greater than 50 VDC from the chassis ground. An output ground potential greater than 50 VDC will damage the amplifier and could cause injury or death to personnel. Copyright © SpectraDynamics, Inc. 1999... -
Page 5: The Back Panel
The Back Panel AC POWER ENTRY MODULE The HPDA-15RM/A is configured to operate on 100 to 120 VAC. Copyright © SpectraDynamics, Inc. 1999... -
Page 6: Operation
“POWER” will turn on. Attach the signal to be distributed to one of the SMA input connectors on the front panel. Any HPDA-15 output may be used to drive the input of another distribution module. Copyright © SpectraDynamics, Inc. 1999... -
Page 7: Specifications
5 MHz and +13 dBm input unless otherwise specified. • • • • 1849 Cherry St. Unit 2. Louisville, CO 80027 Phone: (303) 665-1852 Fax: (303) 604-6088 PECTRA YNAMICS Se habla español Copyright © SpectraDynamics, Inc. 1999... -
Page 8: Warranty
This warranty shall be in effect for one (1) year from the date an HPDA-15RM/A is sold by SDI. SDI makes no other warranty, express or implied, and makes no warranty of the fitness for any particular purpose. SDI’s obligation under this warranty shall not include any transportation charges or costs of installation or any liability for direct, indirect, or consequential damages or delay.
