8.0 Specifications

PARAMETER
Input Power Level 1 dB compression
Bandwidth +/- 1 dB
Gain @ 100 MHz
Impedance Input
Output
Return Loss Input (S11) 100MHz
Output (S22) 100MHz
Distortion +13 dBm
+17 dBm
Isolation Output to output
Output to input
Phase Noise 10 Hz
100 Hz
1 kHz
10 kHz
*All tests done at 100 MHz and +13 dBm input unless otherwise specified.
Rackmount chassis
Storage temperature
Operation environment
Humidity
CONDITIONS
1U H, 19" W, 14" D
-10 to +75 ºC
0 to +50 ºC
5% to 95% Non-condensing
MIN TYP
15 16
- 80-120
- 0.2
- 50
- 50
- -22
- -30
- -43
- -40
95 100
105 110
- -158
- -165
- -171
- -174
MAX UNITS
- dBm
- MHz
0.5 dB
- Ohms
-
-20 dB
-25
-40 dBc
- dB
-
-155 dBc/Hz
-162
-168
-171
