- Page 1 PECTRA YNAMICS, ERFORMANCE ISTRIBUTION MPLIFIER HPDA-100NM PERATING ANUAL PECTRADYNAMICS, NC • 1849 Cherry St. Unit 2 • Louisville, CO 80027 Phone: (303) 665-1852 • Fax: (303) 604-6088 www.spectradynamics.com...
- Page 3 HPDA-100NM Description The HPDA-100NM is a high performance distribution and isolation amplifier. It contains 1 module that provides 5 unity gain outputs. Typical cross channel isolation and reverse isolation is typically greater than 100 dB. The phase noise of the modules is exceptionally low, typically –148 dBc/Hz @ Fourier frequency of 1 Hz and –174 dBc/Hz...
-
Page 4: Safety And Preparation For Use
Power Supply The HPDA-100NM operates on a +20 to +24 VDC supply. The supply voltage should not exceed +24 VDC. The positive power supply should be able to provide 350 mA at the specified output voltage. -
Page 5: The Front Panel
Make sure that the amplifier ground does not float to a potential greater than 50 VDC from the chassis ground. An output ground potential greater than 50 VDC will damage the amplifier and could cause injury or death to personnel. Copyright © SpectraDynamics, Inc. 2012... -
Page 6: The Back Panel
The Back Panel DC POWER ENTRY MODULE The HPDA-100NM is configured to operate on a +20 to +24 VDC NIM supply. Power Entry Module Pinout Pin # 28 +20 to +24 VDC Pin # 34 DC Power GND Pin # 42... -
Page 7: Operation
HPDA distribution amplifier. The red LED located on the top of the front panel labeled STATUS monitors the input level to the module. When a signal is present that exceeds +7 +/- 1 dBm the LED will be on. Copyright © SpectraDynamics, Inc. 2012... -
Page 8: Specifications
Specifications PARAMETER CONDITIONS UNITS Max. Input Power 1 dB compression Bandwidth +/- 1 dB 80 - 120 Gain @ 100 MHz +/- 0.5 Impedance input Ohms output Return Loss input(S11) 5MHz output(S22) 5MHz Distortion +13 dBm Isolation output to output output to input Phase Noise 10 Hz... -
Page 9: Warranty
SDI’s option, any product not meeting the said specifications. This warranty shall be in effect for one (1) year from the date an HPDA-100NM is sold by SDI. SDI makes no other warranty, express or implied, and makes no warranty of the fitness for any particular purpose.
