3.0 Front Panel Description
ACTIVE CH 1 LED
The ACTIVE CH 1 LED will be on when INPUT 1 is the active channel.
ACTIVE CH 2 LED
The ACTIVE CH 2 LED will be on when the INPUT 2 is the active channel.
OUTPUTS
There are ten status indicator LEDs one for each output channel. The status indicator LED
will be on if the signal level of that channel is greater than +7 dBm.
