- Page 1 PECTRADYNAMICS, ERFORMANCE ISTRIBUTION MPLIFIER HPDA15-RM-B PERATING ANUAL PECTRADYNAMICS, NC • 1849 Cherry St. Unit 2. • Louisville, CO 80027 Phone: (303) 665-1852 • Fax: (303) 604-6088...
- Page 2 HPDA15-RM-B Description The HPDA15-RM-B is a high performance distribution and isolation amplifier. It contains 3 modules each of which provide 5 unity gain outputs for every input signal. Typical cross channel isolation is 125 dB and reverse isolation is typically greater than 135 dB.
-
Page 3: Safety And Preparation For Use
To operate the unit, locate the AC power entry connector on the rear panel and connect the power cable. When power is applied to the unit, a red led located on the front panel, labeled “on”, should light up. Copyright © SpectraDynamics, Inc. 1999... -
Page 4: The Front Panel
The LED is on when power is applied to unit and the unit is operating properly. Monitor LED The LED will turn on if the input signal to the corresponding channel is greater than +7 dBm. Copyright © SpectraDynamics, Inc. 1999... -
Page 5: The Back Panel
The Back Panel AC POWER ENTRY MODULE The HPDA15-RM-B is configured to operate on 110 to 120 VAC. SMA INPUTS There are 3 amplifier modules each having one input and 5 outputs. The signal to be distributed should be connected to the SMA jack labeled input. -
Page 6: Operation
“POWER” will turn on. Attach the signal to be distributed to one of the SMA input connectors on the front panel. Any HPDA output may be used to drive the input of another distribution module. Copyright © SpectraDynamics, Inc. 1999... -
Page 7: Specifications
5 MHz and +13 dBm input unless otherwise specified. • • • • 1849 Cherry St. Unit 2. Louisville, CO 80027 Phone: (303) 665-1852 Fax: (303) 604-6088 PECTRA YNAMICS Se habla español Copyright © SpectraDynamics, Inc. 1999... -
Page 8: Warranty
This warranty shall be in effect for one (1) year from the date an HPDA15-RM-B is sold by SDI. SDI makes no other warranty, express or implied, and makes no warranty of the fitness for any particular purpose. SDI’s obligation under this warranty shall not include any transportation charges or costs of installation or any liability for direct, indirect, or consequential damages or delay.
