Power Off

Scan the bar code below to shut off power to the BT handheld until the next trigger pull.

Figure 4-15

Upon completing the physical connection between the reader and its host, proceed directly to

Interface Selection below for information and programming for the interface type the reader is

connected to (for example: RS-232, USB, etc.) and scan the appropriate bar code to select your

system's correct interface type.

USB Com to simulate RS-232 standard interface

Figure 4-16

NOTE:

Install the correct USB Com driver from the CD included with your product.

Select options for USB Keyboard Interfaces.

USB Keyboard with alternate key encoding

Figure 4-17

USB Keyboard with standard key encoding

Figure 4-18

Power Off

Select USB-COM-STD

Select USB Alternate Keyboard

Select USB Keyboard

Power Off
