Brief Introduction Of Installation

The installation of air-conditioner should meet with the "Installation Instruction". The machine
must be installed correctly by professional technicians according to the "Installation
Instruction".

(1) Guide to customer

①The customer should provide a suitable power supply source, its voltage should be in the
range of 90-110% of its rated voltage.
②The power supply circuit should have MCB leakage protection. The capacity should be
more than 1.5 times of the maximum current.
③Must use independent circuit and suitable grounding socket matching with the plug of
air-conditioner.
④The wiring must be installed by qualified electrician according to the electrical safety
requirements.
⑤The air-conditioner must be well grounded, the switch of the main power of air-conditioner
must be reliably grounded.
⑥The power supply wire, must be changed by qualified electrician.

(2) Installation Instruction

1. Installation order
Selection of the installation position Installing the air-conditioner
Expelling the air in the pipes and the indoor unit Connecting the pipes and wires
Testing
2. Selection of the installation position
Indoor Unit:
①There is no heating and steaming source nearby.
②No obstacles for installation position from nearby.
③Keep good air circulation.
④Convenient to adopt measures to reduce noises.
⑤Don't install them near the doorway.
⑥Make sure to have the distance specified in the picture between the ceiling, wall, furniture
and other obstacles.
⑦2 meters high above the floor.
Outdoor Unit:
①In case that you put up a canopy to protect it from rains and sunrays, pay attention not to
cause any obstacles for the heating dispersion for the condenser.
②Don't keep animals or plants near the installation location for the hot air from the outdoor
unit will affect them.
③Make sure to have the distance specified in the picture between ceiling, wall, furniture and
other obstacles.
④Stay away from heating source and inflammable air.
⑤The installation base and supporting frame should be strong and secure. The machine
should be at a level surface.
