Technical Manual
(DC Inverter Free Match R32)
ΑΓΗΝΩΡ A.E.
ΟΜΙΛΟΣ ΕΤΑΙΡΙΩΝ ΤΟΥΡΝΙΚΙΩΤΗ
ΓΕΝΙΚΟΙ ΑΝΤΙΠΡΟΣΩΠΟΙ

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L Series and is the answer not in the manual?

Questions and answers

Related Manuals for AUX L Series

Summary of Contents for AUX L Series

  • Page 1 Technical Manual (DC Inverter Free Match R32) ΑΓΗΝΩΡ A.E. ΟΜΙΛΟΣ ΕΤΑΙΡΙΩΝ ΤΟΥΡΝΙΚΙΩΤΗ ΓΕΝΙΚΟΙ ΑΝΤΙΠΡΟΣΩΠΟΙ...
  • Page 2 AUX DC Inverter Free Match 50HZ KΕΝΤΡΙΚΑ ΓΡΑΦΕΙΑ: Λ. ΑΘΗΝΩΝ 50 & ΣΠ. ΠΑΤΣΗ 8, 10441 ΑΘΗΝΑ ΤΗΛ. ΚΕΝΤΡΟ: 210 5288888, FAX: 210 5221261 SERVICE: 210 5288832-4...
  • Page 3 AUX DC Inverter Free Match 50HZ CONTENTS CONTENTS ........................3 Part1 General Information .................. 7 1. Nomenclature ........................7 2. Unit appearance ......................... 8 3. Combination Table ......................13 4. Accessories Included ......................17 Part2 Features ...................... 18 1. Outdoor Units ........................18 2.
  • Page 4 AUX DC Inverter Free Match 50HZ 1. Wall Mounted ........................30 2. Cassette ..........................38 3. Ceiling Floor ........................41 4. Duct ..........................43 5. Outdoor Unit ........................45 Part5 Dimension ....................52 1. Wall Mounted ........................52 2. Cassette ..........................53 Ceiling Floor .........................
  • Page 5 AUX DC Inverter Free Match 50HZ 5. Equivalent Pipe length conversion ................... 72 Part8 Static pressure curve ................73 1. 07K、09K Duct ......................73 2. 12K Duct ........................74 3. 18K Duct ........................75 Part9 Controller ....................76 1. Controller ......................... 76 2.
  • Page 6 AUX DC Inverter Free Match 50HZ 5. Ceiling Floor ........................161 6. Duct ..........................164 7. Outdoor Unit ........................167 8. Connection piping installation ..................168 9. Emptying or vacuum ...................... 171 10. Insulation........................173 11. Additional refrigerant charge ..................175 12.
  • Page 7 AUX DC Inverter Free Match 50HZ Part1 General Information 1. Nomenclature Indoor Unit Outdoor Unit...
  • Page 8 AUX DC Inverter Free Match 50HZ 2. Unit appearance 2.1 Wall - Mounted Picture Capacity Range / Mode 07 K Btu/h AMWM-H07/4R3(L*) 09 K Btu/h AMWM-H09/4R3(L*) 12 K Btu/h AMWM-H12/4R3(L*) Series 18 K Btu/h AMWM-H18/4R3(L*) 07 K Btu/h AMWM-H07/4R3(F*) 09 K Btu/h...
  • Page 9 AUX DC Inverter Free Match 50HZ 2.2 Cassette Picture Capacity Range / Mode 09 K Btu/h AMCA-H09/4R3A 12 K Btu/h AMCA-H12/4R3A Four-way cassette 18 K Btu/h AMCA-H18/4R3A MB13A-I MB13B-I Standard Panel MB09A MB09B Optional Panel...
  • Page 10 AUX DC Inverter Free Match 50HZ 2.3 Ceiling Floor Picture Capacity Range / Mode 09 K Btu/h AMCF-H09/4R3A 12 K Btu/h AMCF-H12/4R3A Ceiling Floor 18 K Btu/h AMCF-H18/4R3A...
  • Page 11 AUX DC Inverter Free Match 50HZ 2.4 Duct Picture Capacity Range / Mode 07 K Btu/h AMSD-H07/4R3A 09 K Btu/h AMSD-H09/4R3A 12 K Btu/h AMSD-H12/4R3A DUCT 18 K Btu/h AMSD-H18/4R3A...
  • Page 12 AUX DC Inverter Free Match 50HZ 2.5 Outdoor Unit 1 drive 2 14k/18k 1 drive 3 21k/27k Capacity(Btu) （AM2-H14/4DR3） （AM2-H18/4DR3） （ AM3-H27/4DR3） （AM3-H21/4DR3） Picture 1 drive 4 36k 1 drive 5 42k Capacity(Btu) （AM4-H36/4DR3） （AM5-H42/4DR3） Picture...
  • Page 13 AUX DC Inverter Free Match 50HZ 3. Combination Table AM2-H14/4DR3 Suggested Combination One Unit Two Units — 1 drive 2 — — — — Suggested Combination AM2-H18/4DR3 One Unit Two Units 1 drive 2 9+12 7+12 — — — AM3-H21/4DR3...
  • Page 14 AUX DC Inverter Free Match 50HZ AM4-H36/4DR3 Suggested Combination Two Units Three Units Unit 7+12 12+12 7+7+7 7+9+18 9+9+12 12+12+12 7+18 12+18 7+7+9 7+9+24 9+9+18 12+12+18 — 7+24 12+24 7+7+12 7+12+12 9+9+24 1 drive4 — 18+18 7+7+18 7+12+18 9+12+12 9+12...
  • Page 15 AUX DC Inverter Free Match 50HZ AM5-H42/4DR3 Suggested Combination Three Units 7+7+7 7+9+24 9+9+18 12+12+18 7+7+9 7+12+12 9+9+24 12+12+24 7+7+12 7+12+18 9+12+12 12+18+18 7+7+18 7+12+24 9+12+18 12+18+24 1 drive5 7+7+24 7+18+18 9+12+24 18+18+18 7+9+9 7+18+24 9+18+18 — 7+9+12 9+9+9 9+18+24 —...
  • Page 16 AUX DC Inverter Free Match 50HZ Note： All of the above indoor unit can be freely matched and combined, but must be installed strictly according to the above table or the cooling capacity and stability would be decreased.
  • Page 17 AUX DC Inverter Free Match 50HZ 4. Accessories Included 4.1 Outdoor Units QUANTITY N° Name AM2-H14/ AM2-H18/ AM2-H21/ AM3-H27/ AM4-H36/ AM5-H42/ 4DR3 4DR3 4DR3 4DR3 4DR3 4DR3 Installer manual Drainage connector Pipe adaptor copper nuts 4.2 Indoor Units QUANTITY N°...
  • Page 18 AUX DC Inverter Free Match 50HZ Part2 Features 1. Outdoor Units Environmental-friendly Refrigerant R32 The GWP value of R32 is smaller, so the effect on the greenhouse effect is smaller. The ODP value of R32 is 0,so it’s no harm to our planet’s ozone layer.
  • Page 19 AUX DC Inverter Free Match 50HZ Energy Saving Cutting-edge DC inverter of sine wave control and active PFC technology realize low noise and economical operation. Space-Saving Installation Up to 5 indoor units can be connected to a single outdoor unit, which reduces the number of outdoor units required so as to save installation space.
  • Page 20 AUX DC Inverter Free Match 50HZ EXV Regulation Each Indoor Unit adjusted by a EXV,whole unit could achieve quick cooling/heating,and decrease throttling noise in indoor units.
  • Page 21 AUX DC Inverter Free Match 50HZ 2. Wall Mounted Wall Mounted type A/C is installed by the wall, compared with Floor & Standing type A/C, it has following advantages: Wall mounting installation combining with the decoration, makes the room more elegant; Flexible installation in anywhere in the wall and swing blowing, makes you feel more comfortable.
  • Page 22 AUX DC Inverter Free Match 50HZ 3. Four-way Cassette Four-way cassette type A/C is installed under the ceiling, compared with Floor &Standing type A/C, it has following advantages: Ceiling installation combining with the decoration, makes the room more elegant; Flexible installation in anywhere in the ceiling and 4-direction blowing, makes you feel more comfortable.
  • Page 23 AUX DC Inverter Free Match 50HZ 4. Ceiling Floor Ceiling& Foor type A/C can be installed under the ceiling and also on the floor. Compared with normal Floor &Standing type A/C, it can be hoisted under the ceiling,saving room space, it is also the updating Product for Floor &...
  • Page 24 AUX DC Inverter Free Match 50HZ 5. Duct Duct type A/C can be installed under the ceiling and also on the floor. Compared with normal Floor &Standing type A/C, it can be hoisted under the ceiling, saving room space, it is also the updating Product for Floor &...
  • Page 25 AUX DC Inverter Free Match 50HZ 6.WIFI Control The optional WiFi modular makes possible monitor and control your AC while on the road through your mobile phone or pad.
  • Page 26 AUX DC Inverter Free Match 50HZ Part3 Piping System OUTDOOR INDOOR FILTER SERVICE VALVE Tdef TLq-A CONDENSER FILTER PMVA TLq-B FILTER PMVB EVAP B EVAP A SOUND REDUCER Tas-B LPS1 Tas-A 1. 14K, 18K 2. 21K, 27K...
  • Page 27 AUX DC Inverter Free Match 50HZ OUTDOOR INDOOR SERVICE VALVE FILTER TLq-A Tdef FILTER PMVA TLq-B CONDENSER FILTER PMVB TLq-C FILTER PMVC EVAP C EVAP B EVAP A SOUND REDUCER Tas-C LPS1 Tas-B Tas-A...
  • Page 28 AUX DC Inverter Free Match 50HZ SERVICE VALVE OUTDOOR INDOOR FILTER FILTER PMVA FILTER PMVA Tdef FILTER PMVB CONDENSER FILTER PMVC EVAP D EVAP C EVAP B EVAP A SOUND REDUCER HPS1 LPS1 3. 36K...
  • Page 29 AUX DC Inverter Free Match 50HZ 4. 42K SERVICE INDOOR OUTDOOR VALVE FILTER FILTER PMVA FILTER PMVA Tdef FILTER PMVA CONDENSER FILTER PMVB FILTER PMVC EVAP E EVAP C EVAP D EVAP B EVAP A SOUND REDUCER HPS1 LPS1...
  • Page 30 AUX DC Inverter Free Match 50HZ Part4 Specification 1. Wall Mounted 1.1 L Series (07K,09K) Model Indoor Unit AMWM-H07/4R3(L*) AMWM-H09/4R3(L*) Btu/h 7165(3855-9220) 8701(3412~11260) Cooling 2.05(1.13-2.70) 2.55(1.00~3.30) Capacity Btu/h 7510(3340-8530) 9042(3753~11260) Heating 2.15(0.98-2.50) 2.65(1.10~3.30) Power Supply V~,Hz,Ph 220～240,50,1 220～240,50,1 Electric Data Cooling Power 40(12～68)
  • Page 31 AUX DC Inverter Free Match 50HZ 2.2 L Series (12K,18K) Model Indoor Unit AMWM-H12/4R3(L*) AMWM-H18/4R3(L*) Btu/h 12283(4094~12966) 18083(6483~18766) Cooling 3.50(1.20~3.80) 5.30(1.90~5.50) Capacity Btu/h 18425(4777~19107) 12624(3412~12966) Heating 3.50(1.00~3.80) 5.40(1.40~5.60) Power Supply V~,Hz,Ph 220～240,50,1 220～240,50,1 Electric Data Cooling Power 40(12~68) 63(16~88) Heating Power...
  • Page 32 AUX DC Inverter Free Match 50HZ 2.3 F Series (07K,09K) Model Indoor Unit AMWM-H07/4R3(F*) AMWM-H09/4R3(F*) Btu/h 7165(3855-9220) 9000(4780-11260) Cooling 2.05(1.13-2.70) 2.58(1.40-3.30) Capacity Btu/h 7510(3340-8530) 9215(4095-10240) Heating 2.15(0.98-2.50) 2.70(1.20-3.00) V~,Hz, Power Supply 220～240,50,1 220～240,50,1 Electric Data Cooling Power Input 40(12～68) 40(12～68) Heating Power Input 40(12～68)
  • Page 33 AUX DC Inverter Free Match 50HZ 2.4 F Series (12K,18K) Model Indoor Unit AMWM-H12/4R3(F*) AMWM-H18/4R3(F*) Btu/h 12285(5800-12625) 17747(8530-19790) Cooling 3.50(1.70-3.70) 5.27(2.50-5.80) Capacity Btu/h 12625(5120-12625) 18085(7680-19790) Heating 3.50(1.50-3.70) 5.37(2.25-5.80) V~,Hz, Power Supply 220～240,50,1 220～240,50,1 Electric Data Cooling Power Input 40(12～68) 63(16～88) Heating Power Input 40(12～68)
  • Page 34 AUX DC Inverter Free Match 50HZ 2.5 F Series (24K) Indoor Unit AMWM-H24/4R3(F*) Model Btu/h 23986(9895~24908) Cooling 7.03(2.90~7.30) Capacity Btu/h 24054(7165~27296) Heating 7.05(2.10~8.00) Power Supply V~,Hz,Ph 220～240,50,1 Electric Data Cooling Power Input 63(16~88) Heating Power Input 63(16~88) Model YYK50-4 Output Power...
  • Page 35 AUX DC Inverter Free Match 50HZ 2.6 J Series (07K,09K) Model Indoor Unit AMWM-H07/4R3(J*) AMWM-H09/4R3(J*) Btu/h 7165(3855-9220) 9000(4780-11260) Cooling 2.05(1.13-2.70) 2.58(1.40-3.30) Capacity Btu/h 7510(3340-8530) 9215(4095-10240) Heating 2.15(0.98-2.50) 2.70(1.20-3.00) V~,Hz, Power Supply 220～240,50,1 220～240,50,1 Electric Data Cooling Power Input 40(12～68) 40(12～68) 40(12～68)
  • Page 36 AUX DC Inverter Free Match 50HZ 2.7 J Series (12K,18K) Model Indoor Unit AMWM-H12/4R3(J*) AMWM-H18/4R3(J*) Btu/h 12285(5800-12625) 17747(8530-19790) Cooling 3.50(1.70-3.70) 5.27(2.50-5.80) Capacity Btu/h 12625(5120-12625) 18085(7680-19790) Heating 3.50(1.50-3.70) 5.37(2.25-5.80) V~,Hz, Power Supply 220～240,50,1 220～240,50,1 Electric Data Cooling Power Input 40(12～68) 63(16～88) Heating Power Input 40(12～68)
  • Page 37 AUX DC Inverter Free Match 50HZ 2.8 J Series (24K) Indoor Unit AMWM-H24/4R3(J*) Model Btu/h 23986(9895~24908) Cooling 7.03(2.90~7.30) Capacity Btu/h 24054(7165~27296) Heating 7.05(2.10~8.00) Power Supply V~,Hz,Ph 220～240,50,1 Electric Data Cooling Power Input 63(16~88) Heating Power Input 63(16~88) Model YYK50-4 Output Power...
  • Page 38 AUX DC Inverter Free Match 50HZ 2. Cassette 2.1 09, 12K,18K Indoor AMCA-H09/4R3AA AMCA-H12/4R3AA Btu/h 9560(5120-12115) 12285(5800-12625) Cooling 2.80(1.50-3.55) 3.60(1.70-3.70) Capacity Btu/h 10240(5460-13000) 13306(6930-15080) Heating 3.00(1.60-3.81) 3.9(2.03-4.42) V~,Hz,P Power Supply 220~240,50,1 220~240,50,1 Electric Data Cooling Power Input W 70(17.5-109) 70(17.5-109) Heating Power Input W 70(17.5-109)
  • Page 39 AUX DC Inverter Free Match 50HZ mm(inc Gas Side 12.7(1/2) 12.7(1/2) Drainage Loading Qty 20/40/40H unit 147/309/348 147/309/348...
  • Page 40 AUX DC Inverter Free Match 50HZ 2.2 18K Indoor AMCA-H18/4R3AA Btu/h 17060(8530-19107) Cooling 5.0(2.50-5.6) Capacity Btu/h 19107(10340-24000) Heating 5.6(3.03-7.03) Power Supply V~,Hz,Ph 220~240,50,1 Electric Data Cooling Power Input 70(17.5-109) Heating Power Input 70(17.5-109) Model XD30B Output Power Capacitor Speed (Hi/Mi/Lo)
  • Page 41 AUX DC Inverter Free Match 50HZ 3. Ceiling Floor 3.1 09, 12K Model Indoor AMCF-H09/4R3A AMCF-H12/4R3A Btu/h 9560(5120-12115) 12285(5800-12625) Cooling 2.80(1.50-3.55) 3.60(1.70-3.70) Capacity Btu/h 10240(5460-13000) 13306(6930-15080) Heating 3.00(1.60-3.81) 3.9(2.03-4.42) V~ ,Hz, Power Supply 220~240,50,1 220~240,50,1 Electric Data Cooling Power Input...
  • Page 42 AUX DC Inverter Free Match 50HZ 3.2 18K Model Indoor AMCF-H18/4R3A Btu/h 18080(8530-19107) Cooling 5.3(2.50-5.6) Capacity Btu/h 19790(10340-24000) Heating 5.8(3.03-7.03) Power Supply V~,Hz,Ph 220~240,50,1 Electric Data Cooling Power Input 80(20-125) Heating Power Input 80(20-125) Model FP40A-ZL Output Power Indoor Fan Motor...
  • Page 43 AUX DC Inverter Free Match 50HZ 4. Duct 4.1 07, 09K Model Indoor AMSD-H07/4R3A AMSD-H09/4R3A Btu/h 7506(3855-9220) 8872(5120-12115) Cooling 2.20(1.13-2.70) 2.60(1.50-3.55) Capacity Btu/h 8530(4575-10820) 9895(5800-12450) Heating 2.50(1.34-3.17) 2.90(1.70-3.65) Power Supply V~,Hz,Ph 220~240,50,1 220~240,50,1 Cooling Power Electric Data Input Heating Power...
  • Page 44 AUX DC Inverter Free Match 50HZ 4.2 12，18K Model Indoor AMSD-H12/4R3A AMSD-H18/4R3A Btu/h 12280(5835-13135) 17400(8530-19790) Cooling 3.60(1.71-3.85) 5.10(2.50-5.80) Capacity Btu/h 13650(6480-13375) 19790(9690-21835) Heating 4.00(1.90-3.92) 5.80(2.84-6.40) Power Supply V~,Hz,Ph 220~240,50,1 220~240,50,1 Cooling Power Electric Data Input Heating Power Input Model FP40B-ZL...
  • Page 45 AUX DC Inverter Free Match 50HZ 5. Outdoor Unit 5.1 14K, 18K Model AM2-H14/4DR3 AM2-H18/4DR3 INVERTER System Format 1 drive 2 1 drive 2 Btu/h 13989(6142-15388) 18084(6824-19892) Cooling 4.1(1.8-4.51) 5.3(2.0-5.83) Capacity Btu/h 16378(6995-18015) 19107(7541-21017) Heating 4.8(2.05-5.28) 5.6(2.21-6.16) Power Supply V~,Hz,Ph...
  • Page 46 AUX DC Inverter Free Match 50HZ Material Plastic Plastic Outdoor Fan Diameter Ф421×117 Ф421×117 Fan Quantity a. Number Of Row b. Tube Pitch(a)x 22x19.05 22x19.05 Row Pitch(b) c. Fin Pitch Outdoor Coil d. Fin Material Hydrophilic aluminum fin e. Tube Outside φ7，...
  • Page 47 AUX DC Inverter Free Match 50HZ 5.2 21K, 27K DC INVERTER Model AM2-H21/4DR3 AM3-H27/4DR3 System Format 1 drive 3 1 drive 3 Btu/h 21154(7506~22895) 26955(7848~29650) Cooling 6.2(2.2~6.71) 7.9(2.3~8.69) Capacity Btu/h 22519(8155~24771) 27978(8359~30776) Heating 6.6(2.39~7.26) 8.2(2.45~9.02) V~,Hz,P Power Supply 220~240,50,1 220~240,50,1 Cooling Power 1920（350-2800）...
  • Page 48 AUX DC Inverter Free Match 50HZ Diameter Ф470×140 Ф470×140 Fan Quantity a.Number Of Row b.Tube Pitch(a)x 22x19.05 22x19.05 Row Pitch(b) c.Fin Pitch Hydrophilic aluminum Hydrophilic Outdoor Coil d.Fin Material aluminum fin e.Tube Outside φ7， Inner grooved φ7， Inner grooved Dia.And Material f.Coil Length x...
  • Page 49 AUX DC Inverter Free Match 50HZ 5.3 36K, 42K DC INVERTER Model AM4-H36/4DR3 AM5-H42/4DR3 System Format 1 drive 4 1 drive 5 Btu/h 35826(8530~37532) 40944(9451~43332) Cooling 10.50(2.5~11.0) 12(2.77~12.7) Capacity Btu/h 37532(9110~38214) 44356(10100~44800) Heating 11.00(2.67~11.2) 13(2.96~13.1) Power Supply V~,Hz,Ph 220~240,50,1 220~240,50,1...
  • Page 50 AUX DC Inverter Free Match 50HZ Speed r/min Material Plastic Plastic Ф550×125 Ф550×125 Diameter Fan Quantity a.Number Of b.Tube Pitch(a)x 20.5x19.05 20.5x19.05 Row Pitch(b) c.Fin Pitch Outdoor Fan Hydrophilic Hydrophilic aluminum d.Fin Material aluminum fin e.Tube Outside φ7， Inner grooved φ7，...
  • Page 51 AUX DC Inverter Free Match 50HZ Stuffing 20/40/40H unit 44/96/144 44/96/144 Quantity Note: 1. Cooling capacity test Condition:(27℃DB,19℃WB Indoor/35℃DB,24℃WB Outdoor); Heating capacity test Condition:(20℃DB Indoor/7℃DB,6℃WB Outdoor); Connecting pipe length: 7.5M. 2. Data may be changed with unit improvement. We keep the right to change the data or...
  • Page 52 AUX DC Inverter Free Match 50HZ Part5 Dimension 1. Wall Mounted Physical AMWM-H07 AMWM-H09 AMWM-H12 AMWM-H18 Dimension /4R3(L*) /4R3 (L*) /4R3(L*) /4R3(L*) Length Height Width Physical AMWM-H07 AMWM-H09 AMWM-H12 AMWM-H18 AMWM-H24 Dimension /4R3(F*) /4R3(F*) /4R3(F*) /4R3(F*) /4R3(F*) Length 1082 Height...
  • Page 53 AUX DC Inverter Free Match 50HZ 2. Cassette 09K,12K,18K (515) (463) (55)
  • Page 54 AUX DC Inverter Free Match 50HZ 3. Ceiling Floor 09K, 12K, 18K (841)
  • Page 55 AUX DC Inverter Free Match 50HZ 4. Duct 4.1 07K 09K 12K Air Return Air Return Air Outlet Air Outlet...
  • Page 56 AUX DC Inverter Free Match 50HZ 4.2 18K Air Return 1000 1048 (832) Air Outlet (110) Air Outlet...
  • Page 57 AUX DC Inverter Free Match 50HZ 5. Outdoor Unit 5.1 14K, 18K (822) (545)
  • Page 58 AUX DC Inverter Free Match 50HZ 5.2 21K, 27K (854) (540)
  • Page 59 AUX DC Inverter Free Match 50HZ 5.3 36K, 42K (1000) (675)
  • Page 60 AUX DC Inverter Free Match 50HZ Part6 Electrical Principle Diagram 1. Wall Mounted 1.1 L Type (07K,09K,12K,18K) NOTE: "Lo" on the terminal block does not need to be connected. Dotted line part in the frame may not be used. Step Motor...
  • Page 61 AUX DC Inverter Free Match 50HZ 1.2 F Type (07K,09K,12K,18K,24K) NOTE: Dotted line part in the frame may not be used. Step Motor Step Motor AC Fan Motor DC Fan Motor Display receive panel WIFI Module FUSE Forced Switch 3.15A 250V...
  • Page 62 AUX DC Inverter Free Match 50HZ 1.3 J Type (07K,09K,12K,18K,24K) NOTE:if used as MONO unit, for the standby control needs, the cross section area of cable connected to L,Lo,N,S must be sufficient for the maximum system current. The maximum system current is equal to the sum of indoor unit and outdoor unit rated current if used as MULTI unit Lo on the terminal block does not need to be connected.
  • Page 63 AUX DC Inverter Free Match 50HZ 2. Cassette 09K,12K,18K Water Fan Motor Pumb Transformer Step Motor CP 10 AC- N TR- IN PUMB CN 3 TR- 0 L- R AC-L1 Float Switch CN13 CN11 N C(S) Room Temp. Wired WIFI...
  • Page 64 AUX DC Inverter Free Match 50HZ 3. Ceiling Floor 09k, 12k, 18k...
  • Page 65 AUX DC Inverter Free Match 50HZ 4. Duct 07K, 09K, 12K, 18K...
  • Page 66 AUX DC Inverter Free Match 50HZ 5. Outdoor Unit 5.1 14K, 18K, 21K, 27K Electronic Expansion Valve Temperature Sensor Notes: 4-Way Dotted line part in the (T1) (T2) (T3) (T4) (T5) (T11) (T12) (T13)(T14) (T31) (T32) Valve frame may not be used.
  • Page 67 AUX DC Inverter Free Match 50HZ 5.1 36K, 42K...
  • Page 68 AUX DC Inverter Free Match 50HZ Part7 Capacity Amendment 1. Operation range Cooling capacity (KBtu/h) Power supply 220-240V~/50Hz Voltage 187~242V -15~52℃ Cooling Ambient temperature -15~24℃ Heating 2. Capacity amendment of different ambient temperature 2.1 Amendment coefficient of Cooling capacity under different indoor/outdoor DB/WB temperature K1 IDU temp.℃...
  • Page 69 AUX DC Inverter Free Match 50HZ 2.2 Amendment coefficient of Heating capacity under different indoor/outdoor DB/WB temperature K2 IDU temp.℃ Outdoor air inlet DB temperature℃ 0.93 0.97 1.06 1.08 1.14 1.25 0.87 0.93 0.97 1.06 1.08 1.14 0.87 0.93 0.97 1.06...
  • Page 70 AUX DC Inverter Free Match 50HZ 3. Long piping length Cooling capacity (KBtu/h) Φ Φ Φ Φ Liquid pipe 6.35*2 9.52*3 9.52*4 9.52*5 Connection Pipe(mm) Φ Φ Φ Φ Gas pipe 9.52*2 15.88*3 15.88*4 15.88*5 Max. length for all rooms (m) Max.
  • Page 71 AUX DC Inverter Free Match 50HZ 4. Capacity amendment of different piping length 4.1 Amendment coefficients of heating and cooling capacity under different height drop Different Cooling Capacity modified coefficients at different height: Equivalent pipe Note: H = Height of Outdoor Unit － Height of Indoor Unit...
  • Page 72 AUX DC Inverter Free Match 50HZ 4.2 Correction capability Cooling capacity = Rated cooling capacity xK1xK3 Heating capacity = Rated heating capacity xK2xK3 5. Equivalent Pipe length conversion Equivalent pipe length means converting pipe elbow to straight pipe length after considerate the pressure loss.
  • Page 73 AUX DC Inverter Free Match 50HZ Part8 Static pressure curve 1. 07K、09K Duct...
  • Page 74 AUX DC Inverter Free Match 50HZ 2. 12K Duct...
  • Page 75 AUX DC Inverter Free Match 50HZ 3. 18K Duct...
  • Page 76 AUX DC Inverter Free Match 50HZ Part9 Controller 1. Controller Controller IDU type Standard Optional Wall Mounted YK-H(AUX) YK-K(AUX) Cassette YK-K(AUX) XK-04 Ceiling & Floor XK-04 YK-L(AUX) Duct XK05-DY(AUX)120 XK-04 1.1 K series...
  • Page 77 AUX DC Inverter Free Match 50HZ POWER button: Switch the unit ON/OFF. MODE button: Select mode , press the button one time, then the operation modes will change in turn as Auto-Cooling-Dehumidify-Heating TEMP + button and TEMP - button: Temperature adjustment range: 16~32...
  • Page 78 AUX DC Inverter Free Match 50HZ Clock Setting: Normally display the clock set currently (display 12:00 for the first electrifying or resetting). When press the button for 5 seconds, the time display zone will flicker, then press 【+】 and 【-】 button to adjust hour that uses 12-hour clock including “A.M.” and “P.M.” time;...
  • Page 79 AUX DC Inverter Free Match 50HZ 1.2 H series POWER button: Switch the unit ON/OFF. MODE button: Select mode , push the button one time, then the operation modes will change in turn as Auto-Cooling-Dehumidify-Heating TEMP + button and TEMP - button: Temperature adjustment range: 16~32...
  • Page 80 AUX DC Inverter Free Match 50HZ SWING button: Press this button for the first time when operation, it will start the swing function. Push the button for the second time, cancel the swing function. (The function is available matched with the concerned unit)
  • Page 81 AUX DC Inverter Free Match 50HZ...
  • Page 82 AUX DC Inverter Free Match 50HZ 1.3 Wired Controller XK-05/XK-04 XK-05 Features Technical indicator 1. Power source:voltage DC 12V; 2. Work temperature range of PCB:(-10~+70)℃; 3. Work humidity range of PCB:RH20%~RH90%; 4. Button: Touch button 5. Dimensions(W*H*D):120*120*20mm Main functions 1. 8-keytouch button input 2.
  • Page 83 AUX DC Inverter Free Match 50HZ 7.Connect to indoor unit via 3-core shielded cable 8. Receive the signal of wireless remote control XK-05...
  • Page 84 AUX DC Inverter Free Match 50HZ XK-04 Detailed operation instructions (6) 1.【ON/OFF button】 Press- "ON / OFF" button to start or shutdown the unit. 1.1.When the unit is running, users can regulate the operation mode, fan speed, setting temperature, special functions and other parameters on the wired controller XK-05 Set Temp.
  • Page 85 AUX DC Inverter Free Match 50HZ temp.), the other content are not displayed. XK-05 Set Temp. TI M E R FA N S WI NG M ODE Room Temp. FUNCTI ON ON/ OFF XK-04 2.【∧ / ∨ button】 2.1.When the unit is running, press" ∧ " or " ∨ "button to increase or decrease the setting temperature by 1℃.
  • Page 86 AUX DC Inverter Free Match 50HZ XK-04 2.2.Under the function selection mode, press " ∧ " or " ∨ "button to select a function; 2.3.Under the timing mode, press " ∧ " or " ∧ "button to setting time. 3.【Mode button】...
  • Page 87 AUX DC Inverter Free Match 50HZ time of opening up and down swing," " is lighting. At the time of closed, swing icon will disappear.If the unit has positioning swing function, press "Swing" button to regulate the swing angle in the order →...
  • Page 88 AUX DC Inverter Free Match 50HZ XK-05 Time off Room Temp. Room Temp. TI M E R FA N S WI NG M ODE Time on FUNCTI ON ON /OFF Set Temp. Set Temp. XK-04 6.2.After entering timing time setting interface, the default timing time is 0.5H, at this moment, press"...
  • Page 89 AUX DC Inverter Free Match 50HZ 6.3.After the setting of timing, press "Timer" button again to confirm. The timing setting is successful and the time bar will stop blinking. XK-05 Time off Time off Room Temp. Room Temp. TI M E R...
  • Page 90 AUX DC Inverter Free Match 50HZ XK-05 Ti m e o n Ti m e o n Se t Te m p . Se t Te m p . T IM ER F AN SWING M O DE F UNCT IO N...
  • Page 91 AUX DC Inverter Free Match 50HZ Function description (6) The wire controller is for the general-purpose, specific functions fo the controller are subject to the functions of your air conditioning unit. Note: In the interface of function setting, press any button such as Timer, Fan, Swing, Mode, ON/OFF, and Comfort to exit the interface and conventional operation interface will display.
  • Page 92 AUX DC Inverter Free Match 50HZ XK-05 Sleep Se t Te m p . TI MER SWI NG MODE TI MER SWI NG MODE FUNCTI ON ON/OFF FUNCTI ON ON/ OFF Sleep Se t Te m p . Se t Te m p .
  • Page 93 AUX DC Inverter Free Match 50HZ Sleep Se t Te m p . Ec o TI MER SWI NG MODE FUNCTI ON ON/ OFF Turbo Se t Te m p . TI MER SWI NG MODE FUNCTI ON ON/OFF XK-04...
  • Page 94 AUX DC Inverter Free Match 50HZ XK-05 Sleep Se t T e mp . T IM ER F AN SWING M O DE F UNCT IO N O N/O F F Sleep Se t T e mp . T IM ER...
  • Page 95 AUX DC Inverter Free Match 50HZ Sleep T IM ER F AN SWING M O DE Se t T e mp . F UNCT IO N O N/O F F Se t T e mp . T IM ER F AN...
  • Page 96 AUX DC Inverter Free Match 50HZ XK-05 Sleep TI MER SWI NG MODE TI MER SWI NG MODE Se t Te m p . FUNCTI ON ON/ OFF FUNCTI ON ON/OFF Sleep Se t Te m p . Se t Te m p .
  • Page 97 AUX DC Inverter Free Match 50HZ Sleep Se t Te m p . TI MER SWI NG MODE FUNCTI ON ON/OFF Se t Te m p . TI MER SWI NG MODE FUNCTI ON ON/OFF XK-04 4. 【"Mildew-proof"】 Mildew-proof function: After shutdown, the air conditioner would automatically dry the moisture in the evaporator of indoor unit, so as to avoid mildewing.
  • Page 98 AUX DC Inverter Free Match 50HZ Sleep TIMER SWING MODE Se t Te m p . TIMER SWING MODE FUNCTION ON/OFF FUNCTION ON/ OFF Sleep Se t Te m p . Se t Te m p . TIMER SWING MODE...
  • Page 99 AUX DC Inverter Free Match 50HZ XK-04 5.【"Light Sensation"】 Light sensation function: Detect the On and Off of indoor lamplight and switch o low fan speed when the lamplight is off, which can reduce the noise and create a comfortable sleep environment...
  • Page 100 AUX DC Inverter Free Match 50HZ Sleep Se t Te m p . TI MER SWI NG MODE TI MER SWI NG MODE FUNCTI ON ON/OFF FUNCTI ON ON/OFF Sleep Se t Te m p . Se t Te m p .
  • Page 101 AUX DC Inverter Free Match 50HZ Sleep Se t T e mp . T IM ER F AN SWING M ODE F UNCT ION ON/ OF F Se t T e mp . T IM ER F AN SWING M ODE...
  • Page 102 AUX DC Inverter Free Match 50HZ ",until it is finished XK-05 Ro o m T e mp . Ro o m T e mp . T IM ER F AN SWING M O DE C l e an F UNCT IO N O N/O F F Ro o m T e mp .
  • Page 103 AUX DC Inverter Free Match 50HZ If the unit is not equipped with a WIFI function module, the icon " " does not display 2.【"Shielding"】function display When unit is locked by centralized control, the wired controller will display 3.【"Mute"】 function display When the unit enter silent function, display "...
  • Page 104 AUX DC Inverter Free Match 50HZ Fahrenheit temperature synchronously. 7.【"Child Lock" function display】 Press both" ∧ " or " ∧ " buttons for more than 5S to enter locking, the controller will display " " . In the state of locking, operations on the wired controller are disabled (but remote control receiving is valid).
  • Page 105 AUX DC Inverter Free Match 50HZ 1. Power supply: voltage DC 12V; Wired 2. Work temperature range of PCB:(-10~+70)℃; controller 3. Work humidity range of PCB:RH20%~RH90%;...
  • Page 106 AUX DC Inverter Free Match 50HZ 2. Parameters Setting Indoor unit’s parameters can be set by remote controller (YK-L) and wired remote controller—For after-sales (In indoor side ,After a new PCB was replaced, indoor parameters set is necessary). 2.1 Parameter Setting table 【04】...
  • Page 107 AUX DC Inverter Free Match 50HZ address setting mode. Parameter Setting ③ Press the [∧] or [∨] button to change the parameter series number ④ Press the [IClean] or [ECO] button to change the parameter correspondence ⑤ Press the [MODE] button to send order (Sent signal to display panels or receivers), Then...
  • Page 108 AUX DC Inverter Free Match 50HZ 2.3 Parameter Setting by XK-04/ XK-05 Parameter checking Press the “FUNCTION” button for 5 seconds, enter into the parameter checking interface . the wired controller’s address will be displayed in the temperature zone of LED screen ( press “FUNCTON”...
  • Page 109 AUX DC Inverter Free Match 50HZ The corresponding parameter valve ”MM” begain to flash, changing it throuth pressing the “ ” or “ ” burton, after finished ,press the “FUNCTION” button to confirm. When finishing parameter setting,it will automatically go back to parameter checking model.
  • Page 110 AUX DC Inverter Free Match 50HZ ③ Press “FUNCTION” for 5S again, enter parmater setting model; 04 11 Press the“ ”or“ ”button to get “ ” ② ① Press “FUNCTION” for 5S,enter parmater check model; 【0411】change to 【0439】 （step2） 04 39 Press the“...
  • Page 111 AUX DC Inverter Free Match 50HZ 3. Room Card Function 3.1 Function setting Contact Parameter Model Operation model specification setting State 0900 Stand （default) The IDU Will be into standby mode, can be controlled by controller Room Card 0901 (optional)
  • Page 112 AUX DC Inverter Free Match 50HZ 09 01 ④ Press the“ ”or“ ”button to get “ ” ⑤ after finishing setting , press “FUNCTION”to confirm 3.2 Wiring diagram When the room card is inserted, the air conditioning can be controlled ; when you leave the room, the AC will standby, can ’t be controlled .
  • Page 113 AUX DC Inverter Free Match 50HZ 4. Wifi Module 4.1 WiFi Module Configuration ① APP Download Mobile terminal scan the following dimensional code to download APP, or search “AC Freedom” in APPSTORE and Google store ② Light Commercial WIFI Module Installation...
  • Page 114 AUX DC Inverter Free Match 50HZ the configuration ⚫ Connect mobile terminals to WIFI, open APP “AC Freedom”, and then operate following the steps below: Note:If the configuration fails or you change the password of wireless router, you need to reset the WIFI module to reconnect: Turn on the power of the module, then repeat the steps above for APP configuration.
  • Page 115 AUX DC Inverter Free Match 50HZ ⚫ Make sure the WIFI box for wiring is properly connected. ⚫ Long press WIFI box 8 seconds to reconfigure the positive button. If the problem can't be solved, please contact after sales person.
  • Page 116 AUX DC Inverter Free Match 50HZ Part10 Explosive View 1. Wall Mounted 1.1 L Type ( 07K, 09K, 12K) 27 26...
  • Page 117 AUX DC Inverter Free Match 50HZ Material code Part name 11220502004504 Panel 11222014000521 Display board assembly 11220508000142 Filter 11320096000105 Screw cover 11220509000062 Medium frame wiring cover 11320078000196 Right-side cover 11320065000028 Breakwater 11220513000067 Air blade 11230003000127 Indoor motor 11320052000032 Motor cover...
  • Page 118 AUX DC Inverter Free Match 50HZ 1.2 L Type (18K)
  • Page 119 AUX DC Inverter Free Match 50HZ Material code Part Name 11320003003301 Panel 11320005000388 air louver（Horizontal） 11320094000054 Decoration board 11222014000522 Display board assembly 11220508000144 Filter 11320076000057 Medium frame wiring cover 11321071000006 Medium frame wiring cover scale board 11320096000104 Screw cover 11320078000207...
  • Page 120 AUX DC Inverter Free Match 50HZ 1.3 F Type ( 07K, 09K, 12K)
  • Page 121 AUX DC Inverter Free Match 50HZ Material code Part name 11220502004342 Decro panel 11320135000018 Air louver（Horizontal） 11220508000139 Filter 11320096000104 Screw cover 11320076000084 Medium frame wiring cover 11320002000305 Medium frame 11320085000094 Guide vane linkage 11320017000125 Left-right swing blade 11320127000007 Step motor bracket...
  • Page 122 AUX DC Inverter Free Match 50HZ 18 19 16 17...
  • Page 123 AUX DC Inverter Free Match 50HZ Material code Part name 11321003000028 Mounting plate assembly 11320084000014 Pipe clamp 11230005000013 IDU fan motor 11220513000066 Scroll fan 11224003000695 Evap asm 11320052000043 Fan motor cover 11220551000003 bearing assembly 11220500000213 Chassis assembly 11220508000140 Filter 11320002000303...
  • Page 124 AUX DC Inverter Free Match 50HZ 1.5 F Type (24K) 11 12...
  • Page 125 AUX DC Inverter Free Match 50HZ BOM Code Part Name Quantity 11320003002072 panel 11320005000288 air louver（Horizontal） 11222014000608 display board 11220508000138 filter 11320096000075 Screw cover 11320076000057 medium frame wiring cover 11320002000233 medium frame 11320017000110 left-right swing blade 11320135000008 air louver 11320079000016...
  • Page 126 AUX DC Inverter Free Match 50HZ 1.6 J Type ( 07K, 09K, 12K) 13.1 13.2 13.3 18 9.9 9.10 19.1 19.2 19.3 19.4 19.5 19.7 19.6...
  • Page 127 AUX DC Inverter Free Match 50HZ Chinese Name Part Name Part Code Quantity Panel 11320003002875 面板 Display board assembly 11222014000608 显示灯板组件 Air louver（Horizontal） 11320005000359 导风门 Screen assembly 11220508000146 过滤网组件 Medium frame panel 11320088000038 中框装饰板 Left cover 11320078000159 左端盖 Medium frame 11320002000292 中框...
  • Page 128 AUX DC Inverter Free Match 50HZ 19.1 电控盒屏蔽盒 A Electric control box shielding box A 11321020000033 19.2 电控盒屏蔽盒 B Electric control box shielding box B 11321020000034 19.3 Control box 11320057000082 电控盒 19.4 Main control board 11222009003550 主控板 19.5 Transformer 11329009000014 变压器...
  • Page 129 AUX DC Inverter Free Match 50HZ 1.7 J Type ( 18K) 29 30 31 32 33 27 28 23 22 19 18...
  • Page 130 AUX DC Inverter Free Match 50HZ Chinese Name Part Name Part Code Mounting plate assembly 11321003000028 挂板组件 Motor support plate 11320074000004 电机支撑板 Indoor fan motor 11230005000013 室内电机 The motor holder 11320087000030 电机压板 The motor holder 11320087000031 电机压板 Evaporator left side carriage 11320015000138 蒸发器左支架...
  • Page 131 AUX DC Inverter Free Match 50HZ Cover of electric controller box 11320058000068 电控盒盖 Terminal board 11330037000136 端子板 Cover of electric controller box sheet-metal 11321020000038 电控盒盖屏蔽板 Electric control box cover 11320058000069 电控盒护盖 Wire clamp 11320010000045 压线板 Hold climbing 11320049000007 抱攀 Transformer 11329009000022 变压器...
  • Page 132 AUX DC Inverter Free Match 50HZ 1.8 J Type ( 24K) 13.2 13.1 13.3 13.4 9.1 9.2 13.5 18.2 18.1 18.3 18.5 18.4 18.6 18.8 18.7...
  • Page 133 AUX DC Inverter Free Match 50HZ Chinese Name Part Name Part Code Panel 11320003002880 面板 Display board 11222014000608 显示灯板 Air louver（Horizontal） 11320005000360 导风门 Filter 11220508000145 过滤网 Screw cover 11320096000102 螺钉盖 Medium frame wiring cover 11320076000105 中框接线盖 Medium frame decorating plate 11320088000039 中框装饰板...
  • Page 134 AUX DC Inverter Free Match 50HZ Air louver step motor 11230002000152 导风门步进电机 Step motor shaft sleeve 11320079000016 步进电机轴套 Main controller 11222003002918 主控制器 18.1 Control box 11320057000066 电控盒 18.2 电控盒盖 1 Cover of electric control box 11321020000029 18.3 Transformer 11329009000014 变压器...
  • Page 135 AUX DC Inverter Free Match 50HZ 2. Cassette 09K,12K,18K...
  • Page 136 AUX DC Inverter Free Match 50HZ Chinese Name Part Name BOM Code panel 16108022000017 面板 Shaft bushing of damper 16420009000009 导风门轴套 air return grille 16420010000033 回风格栅 Motor Assembly 16320005000042 步进电机 Guide the wind vane 16420007000035 导风条 Filter net 16420012000012 过滤网...
  • Page 137 AUX DC Inverter Free Match 50HZ 3. Ceiling Floor 09K,12K,18K 18 19...
  • Page 138 AUX DC Inverter Free Match 50HZ Chinese Name Part Name BOM Code air return grille 16420012000002 格栅 Filter net 16420010000002 滤网 Adornment board 16420015000002 左装饰板 electric control box 16421038000364 电器盒 Electric cover plate 16421005000205 电控盒盖 Terminal plate 16427001000087 端子板 Terminal plate 16427001000064 端子板...
  • Page 139 AUX DC Inverter Free Match 50HZ 4. Duct 4.1 07K,09K,12K...
  • Page 140 AUX DC Inverter Free Match 50HZ Chinese Name Part Name BOM Code Right plate 16421001000768 右侧板 底盘 A Chassis A 16421005000622 底盘 B Chassis B 16421005000619 Volute mounting plate 16421002000492 蜗壳固定板 Motor support 16430001000599 电机支架组件 Lower spiral case 16444002000023 下蜗壳...
  • Page 141 AUX DC Inverter Free Match 50HZ 4.2 18K...
  • Page 142 AUX DC Inverter Free Match 50HZ Chinese Name Part Name BOM Code Right plate 16421001000768 右侧板 底盘 A Chassis A 16421005000620 底盘 B Chassis B 16421005000623 Volute mounting plate 16421002000493 蜗壳固定板 Motor support 16430034000007 电机及支架组件 Lower spiral case 16444002000023 下蜗壳...
  • Page 143 AUX DC Inverter Free Match 50HZ 5. Outdoor Unit 5.1 14K， 18K...
  • Page 144 AUX DC Inverter Free Match 50HZ Chinese Name Part name Part code Qty/Per Front panel 11321005000107 前面板 Plastic grille 11320026000061 出风网罩 Fan blade 11320009000063 风叶 Left side panel 16421001000729 左侧板 Condenser asm 16324002000103 冷凝器 Motor bracket 11321002000040 电机支架 Electric board asm 11222550000016 电控总成...
  • Page 145 AUX DC Inverter Free Match 50HZ...
  • Page 146 AUX DC Inverter Free Match 50HZ Chinese Name Part name Part code Qty/Per Front panel 16421004000355 前面板 Plastic grille 11320026000052 出风网罩 Fan blade 11320009000064 风叶 Left side panel 16421001000736 左侧板 Condenser asm 16324002000102 冷凝器 Motor bracket 11321002000036 电机支架 Electric board asm 11222550000017 电控总成...
  • Page 147 AUX DC Inverter Free Match 50HZ 5.3 36K...
  • Page 148 AUX DC Inverter Free Match 50HZ Chinese Name Part name Part code Qty/Per Electric board asm 11222550000021 控制器总成 Electric Box 11320057000110 电控盒 Electric Box cover 11320058000088 电控盒盖 11222542000106 控制板 Radiator 11329031000064 散热器 Electrical cover 11320068000006 电器盖板 valve cover 16421014000090 阀板...
  • Page 149 AUX DC Inverter Free Match 50HZ 5.4 42K...
  • Page 150 AUX DC Inverter Free Match 50HZ Chinese Name Part name Part code Qty/Per Electric board asm 11222550000021 控制器总成 Electric Box 11320057000110 电控盒 Electric Box cover 11320058000088 电控盒盖 11222542000106 控制板 Radiator 11329031000064 散热器 Electrical cover 11320068000006 电器盖板 valve cover 16421014000090 阀板...
  • Page 151 AUX DC Inverter Free Match 50HZ Part11 Installation 1. Preparation Please buy following spare parts from your local market before installation Hung bolts M12, 4 pcs Drainage pipe PVC Copper connecting pipe Adhesive belt (big size) 5 pcs, (small size) 5 pcs...
  • Page 152 AUX DC Inverter Free Match 50HZ 2. Precaution ◇ Hanging location should be able to support the unit’s weight, there should be no increase in noise and vibration. If the hanging location needs reinforcement, it should be reinforced before installation;...
  • Page 153 AUX DC Inverter Free Match 50HZ 3. Wall Mounted 3.1 Spacing Reserved 3.2 Hoisting of Indoor Unit ◇ The wall for installing indoor unit should be firm to prevent vibration. Horizontally install hanging plate on the wall with four cruciform screws to keep laterally horizontal and longitudinally vertical.
  • Page 154 AUX DC Inverter Free Match 50HZ 3.4 Drainage Checking In case of maintenance, remove grille from casing of the unit according to the following procedures: ◇ As shown in right diagram, remove two screw caps on both sides of the front grille and then screw down two fixing screws.
  • Page 155 AUX DC Inverter Free Match 50HZ 4. Cassette 4.1 Installation drawing...
  • Page 156 AUX DC Inverter Free Match 50HZ 4.2 The distance between indoor unit and obstacle 4.3 Indoor unit suspension ◇ Select the suspension foundation: The suspension foundation is a structure of either wooden frame or reinforced concrete. It must firm and reliable to bear at least 4 times weight of itself and capable of bearing vibration for long periods.
  • Page 157 AUX DC Inverter Free Match 50HZ ◇ If this unit is installed on a sloping ceiling, a cushion block should be installed between the ceiling and the air outlet panel, in order to ensure that the unit is installed on a level surface.
  • Page 158 AUX DC Inverter Free Match 50HZ 4.4 Drainage pipe installation The drainage pipe should be properly insulated to prevent the generation of condensation. Heat insulation material: the thickness of rubber insulation pipe should be more than 8mm ◇ Drainage pipe must have a downward gradient (1 / 50 1 / 100) to avoid water backflow or leakage etc.
  • Page 159 AUX DC Inverter Free Match 50HZ ◇ When draining multiple units into a common drain line, this common drain should be installed about 100mm below each units drain outlet, as shown in the drawing. ◇ When finish installation please carry out the drainage test to ensure that the water flow through the pipeline fluently, and carefully observe the junction to ensure that there is no water leakage.
  • Page 160 AUX DC Inverter Free Match 50HZ...
  • Page 161 AUX DC Inverter Free Match 50HZ 5. Ceiling Floor 5.1 Installation spacing 5.2 Indoor unit suspension ◇ Select the suspension foundation ◇ The suspension foundation is a structure of either wooden frame or reinforced concrete. It must be firm and reliable to bear at least 4 times weight of itself and capable of bearing vibration for long periods;...
  • Page 162 AUX DC Inverter Free Match 50HZ ◇ Tighten the bolt and ensure that four hooks are in close contact with the nuts and washers, and the unit is suspended firmly and reliably onto the hooks. ◇ After the unit is installed ensure it is secure and does not shake or sway.
  • Page 163 AUX DC Inverter Free Match 50HZ through the pipeline fluently, and carefully observe the junction to ensure that there is no water leakage at the junction. If the unit is installed in the newly built house, strongly recommend that this test taken before the CFiling installation. Even it is the heating only unit, this test is...
  • Page 164 AUX DC Inverter Free Match 50HZ 6. Duct 6.1 Installation spacing Air Outlet Air Return Air Outlet Air Return A （mm） B（mm） C（mm） D （mm） E（mm） F（mm） G （mm） H （mm） I（mm） Model 1000 1048 110- 6.2 Indoor unit suspension Warning：...
  • Page 165 AUX DC Inverter Free Match 50HZ 6.3 Installation of duct There are two installation methods of duct ,as follow. 6.4 Drainage pipe ⚫ The drainage pipes should have good insulation measures. The specific steps are as follows: a) The drainage hoses should be tightly clambed with the inner water outlet and the drainage...
  • Page 166 AUX DC Inverter Free Match 50HZ ⚫ There is a drain hole on each side of indoor unit;unused drain pipe must be closed. Note：The drain pipe must be wrapped heat insulation material, otherwise it will cause condensation or water drops.
  • Page 167 AUX DC Inverter Free Match 50HZ 7. Outdoor Unit 7.1 Installation location ◇The site shall be strong enough to bear its weight, prevent noise and vibration. ◇The site shall be ensured to avoid direct sunshine, if necessary set a Havelock above the outdoor unit.
  • Page 168 AUX DC Inverter Free Match 50HZ Note: Require A＞300mm; B＞1500mm; C＞300mm; D＞500mm; 7.3 Installation Foundation ◇Use size M10 bolt and nut to fasten the outdoor unit tightly on the bracket, keep it in the horizontal level. The suitable length for bolt shall 20mm over the base level, in order to minimize vibration please do set a rubber shock absorber.
  • Page 169 AUX DC Inverter Free Match 50HZ ◇If there are many points to be welded ,please set a filter in the pipe(buy from local market) ◇Please use nitrogen gas or air to remove the dust and water in the pipe, ◇Please lay out the piping according to the tend towards of the piping, but it is not allowed more than 3 times curved at the same point of the pipe(if do like this the pipe will become rigid) ◇When using pipe bending machine, the curvature shall not be too small or it will affect the...
  • Page 170 AUX DC Inverter Free Match 50HZ 8.2 Piping specification selection As to the detail selection please take reference to the cooling capacity adjust index figure during different installation situations. Expanding size Piping diameter Tighten torque Expanding shape Paint the frozen oil 1/4in(φ6.35mm)
  • Page 171 AUX DC Inverter Free Match 50HZ Equivalent pipe length conversion Equivalent pipe length means converting pipe elbow to straight pipe length after considerate the pressure loss. Elbow and Oil loop conversion tablet Type Bend Oil Loop Pipe Dia.(mm) 6.35 0.10 9.52...
  • Page 172 AUX DC Inverter Free Match 50HZ 3. Turn off the pressure gauge and vacuum pump to keep the pressure in the same level in 20 minutes. ◇Emptying: when process this operation, please disconnect the high pressure valve with liquid valve.
  • Page 173 AUX DC Inverter Free Match 50HZ 10. Insulation ◇ Use heat insulation material with good insulation performance to wrap the pipe.
  • Page 174 AUX DC Inverter Free Match 50HZ Notes Drainage pipe and connection piping should be wrapped by heat insulation material respectively lift the air conditioner is proved my dew conditioner experiment. But if it keeps on working in high humidity (the dew temperature is more than23℃) environment which may lead to water leakage, please use following additional insulation material: ◇Glass fiber insulation material with the thickness between 10~20mm can be used.
  • Page 175 AUX DC Inverter Free Match 50HZ 11. Additional refrigerant charge When pipe length exceeds 7.5m, please add refrigerant according to the table below: Piping size) Connection Additional refrigerant piping charge amount (kg/m) Gas pipe Liquid pipe φ9.52×0.75mm φ6.35×0.75mm 0.02 φ12.7×1mm φ6.35×0.75mm...
  • Page 176 AUX DC Inverter Free Match 50HZ 12. Electrical connection 12.1Electrical connection precaution Installation of electric items must be carried out by qualified, professional technicians. An isolated circuitry should be fixed with whole-pole disconnection devices, which is with at least 3mm gap of touch point Power supply and indoor to outdoor connection wire should use special cable.
  • Page 177 AUX DC Inverter Free Match 50HZ 12.2 Specification of wire Wiring Diagram of Indoor Unit and Outdoor Unit Power line must be properly fixed; Outdoor unit must be grounded; Each indoor unit must be grounded; Power wire must be thickened when it is overlong.
  • Page 178 AUX DC Inverter Free Match 50HZ Notice: Above mentioned power supply cord is the cable which connect air on-off of indoor to indoor/outdoor unit. Power supply cord of indoor/outdoor unit is the power supply cable connecting indoor and outdoor unit The section area of power supply cord core is minimized one.
  • Page 179 AUX DC Inverter Free Match 50HZ ◇ After confirmation of normal working condition, press the “on-off” button to stop the system. ◇ At last, train the end users with operation, maintaining and special notice.
  • Page 180 AUX DC Inverter Free Match 50HZ Part12 PCB Instruction 1. Outdoor Unit PCB 1.1 14K,18K Main PCB and Driver modular...
  • Page 181 AUX DC Inverter Free Match 50HZ 1.2 21K,27K Main PCB and Driver modular...
  • Page 182 AUX DC Inverter Free Match 50HZ 1.3 36K,42K Main PCB...
  • Page 183 AUX DC Inverter Free Match 50HZ Drive Modular Board...
  • Page 184 AUX DC Inverter Free Match 50HZ 2. Indoor Unit PCB 2.1 09K,12K,18K(Cassette)
  • Page 185 AUX DC Inverter Free Match 50HZ 2.2 09K,12K,18K(Ceilling&Floor)
  • Page 186 AUX DC Inverter Free Match 50HZ 2.3 07k,09K,12K,18K(Duct)
  • Page 187 AUX DC Inverter Free Match 50HZ Part13 Trouble Shooting 1. Failure code display ERROR ERRO CODE CODE DESCRIPTION (display (wired board) controller) Fault with the over-electric current protection Fault with the Compressor Power supply Phase deficiency protection Fault with the inverter module protection(IPM)
  • Page 188 AUX DC Inverter Free Match 50HZ fault with the low pressure switch fault with the low pressure fault of four way valve fault with the High pressure switch Protection high temperature discharge Fault with anti-high temperature protection of indoor unit in...
  • Page 189 AUX DC Inverter Free Match 50HZ 2. Failure analysis 2.1【H2】Wired controller communication failure...
  • Page 190 AUX DC Inverter Free Match 50HZ 2.2【E5】Communication failure between indoor and outdoor unit...
  • Page 191 AUX DC Inverter Free Match 50HZ Outdoor protection(phase sequence)
  • Page 192 AUX DC Inverter Free Match 50HZ 2.3【P2】high pressure protection Cooling high pressure protection Heating high pressure protection...
  • Page 193 AUX DC Inverter Free Match 50HZ 2.4【H6】low pressure protection...
  • Page 194 AUX DC Inverter Free Match 50HZ Cooling low pressure protection Heating low pressure protection...
  • Page 195 AUX DC Inverter Free Match 50HZ 2.5【P5】High exhaust temperature protection...
  • Page 196 AUX DC Inverter Free Match 50HZ Cooling exhaust temperature protection...
  • Page 197 AUX DC Inverter Free Match 50HZ Heating exhaust temperature protection...
  • Page 198 AUX DC Inverter Free Match 50HZ 2.6【H8】four way valve failure protection...
  • Page 199 AUX DC Inverter Free Match 50HZ 2.7 Sensor failure protection...
  • Page 200 ΑΓΗΝΩΡ A.E. ΟΜΙΛΟΣ ΕΤΑΙΡΙΩΝ ΤΟΥΡΝΙΚΙΩΤΗ ΓΕΝΙΚΟΙ ΑΝΤΙΠΡΟΣΩΠΟΙ KΕΝΤΡΙΚΑ ΓΡΑΦΕΙΑ: Λ. ΑΘΗΝΩΝ 50 & ΣΠ. ΠΑΤΣΗ 8, 10441 ΑΘΗΝΑ ΤΗΛ. ΚΕΝΤΡΟ: 210 5288888, FAX: 210 5221261 SERVICE: 210 5288832-4...
