- Page 1 CPT-385A PC to Video Converter Operation Manual CPT-385A...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Introduction................... 1 2. Main Features................1 3. Hardware Description..............2 3.1 Front Panel................2 3.2 Rear Panel................2 3.3 Side Panel................2 4. Appendix..................3 4.1 Specifications................3 5. Troubleshooting................3... -
Page 4: Introduction
1. Introduction The CPT-385A PC to Video scan converter box is designed to convert a variety of computer images, from 640x480 up to 1600x1200, to interlaced NTSC or PAL video. It support output formats including composite and S-Video. -
Page 5: Hardware Description
3. Hardware Description The following sections describe the hardware components of the CPT-385A. 3.1. Front Panel PC to Video INPUT POWER . Power: Press to turn power On and Off. . PC input VGA connector. . DC power supply 5V/1A DC. -
Page 6: Appendix
Power not available. electronic devices are working correctly. Press power button to turn System may be in standby On/Off LED in red color on the CPT-385A. mode. Check that the A/V A/V connection may be No Picture cables are connected loose. - Page 7 2007.8.14 MPM-CPT385A...
- Page 8 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw...
