AWARD BIOS
Integrated Peripherals
Onboard Parallel
Port
3BC/IRQ7
378/IRQ7
278/IRQ7
Disabled
Integrated Peripherals
Parallel Port Mode
Normal
SPP
EPP 1.7 + SPP
EPP 1.9 + SPP
ECP
EPP 1.7 + ECP
EPP 1.9 + ECP
Integrated Peripherals
ECP Mode Use DMA
3
1
3-28
Onboard Parallel Port
This item controls the onboard parallel port address
and interrupt.
Note: If you are using an I/O card with a
parallel port, make sure that the addresses
and IRQ do not conflict.
Parallel Port Mode
This item lets you set the parallel port mode. The
mode options are Normal (Standard and Bidirection
Parallel Port), EPP (Enhanced Parallel Port) and ECP
(Extended Parallel Port). Normal is the IBM AT and
PS/2 compatible mode. EPP enhances the parallel
port throughput by directly writing/reading data to/from
parallel port without latch. ECP supports DMA and
RLE (Run Length Encoded) compression and
decompression. EPP1.7 and EPP1.9 are protocol
difference.
ECP Mode Use DMA
This item lets you set the DMA channel of ECP mode.
