Integrated Peripherals
Onboard UART 2
Mode
Standard
HPSIR
ASKIR
•
-
Standard
default setting.
•
-
HPSIR Select this setting if you installed an Infrared module in your
system via IrDA connector (refer to section 2.3 "Connectors").
setting allows infrared serial communication at a maximum baud rate of
115K baud.
•
-
ASKIR Select this setting if you installed an Infrared module via IrDA
connector (refer to section 2.3 "Connectors"). This setting allows infrared
serial communication at a maximum baud rate of 19.2K baud.
Note: If you are using an network card, make
sure that the interrupt does not conflict.
Onboard UART 2 Mode
This item is configurable only if the "Onboard UART
2" is enabled. This allows you to specify the mode
of serial port2. The available mode selections are:
Sets serial port 2 to operate in normal mode. This is the
AWARD BIOS
This
3-27
