AOpen AX59PRO User Manual page 14

Overview
Zero Voltage Modem
Wake Up
LAN Wake Up
RTC Wake Up Timer
Synchronous
Switching Regulator
Over-current
Protection
CPU Thermal
Protection
Fan Monitoring
System Voltage
Monitoring
1-4
Special circuit (patent applied) to support modem
wake up by external box modem or internal AOpen
F56/MP56 modem card.
By using a network card that supports this feature
and a network management software, you can wake
up a system through a local area network.
Program the date/time to wake up your system.
High efficient synchronous switching regulator for
future CPU.
CPU core voltage 15A over-current protection to
prevent any accident short circuit.
Warning when CPU temperature is higher than a
predefined value.
Three fan connectors, warning when CPU or housing
fan is malfunction.
Warning when system voltage (5V,12V,3.3V,2.8V)
are abnormal.
