For Internal Modem Card (AOpen MP56):
1. Go into BIOS setup , Power Management
Enable.
2. Setup your application, put into Windows 95.
3. Turn system power off by soft power switch.
4. Connect 4-pin Modem Ring-On cable from MP56 RING connector to AX59
Pro connector WKUP.
5. Connect telephone line to MP56. You are now ready to use Modem Ring-
On.
For External Box Modem:
1. Go into BIOS setup , Power Management
Enable.
2. Setup your application, put into Windows 95 Start Up.
3. Turn system power off by soft power switch.
4. Connect RS232 cable of external box Modem to COM1 or COM2.
5. Connect telephone line to external box Modem. Turn on Modem power (you
must keep Modem power always on). You are now ready to use Modem
Ring
Tip: External modem wake up signal is detected through
COM1 or COM2. Internal modem card wake up signal is
detected through cable from connector RING (on modem
card) to WKUP (on mainboard).
Note: If you use external modem, the power of external
modem must be kept on to receive signal from telephone
line. Internal modem card has no such limitation.
Overview
Modem Wake Up, select
Modem Wake Up, select
1-9
