Chapter 2 — Installation

Memory Cartridge

The EasyCoder PC4 is fitted with 1 MB built-in flash memory and 2
MB DRAM. The built-in memory can be expanded using an exchange-
able memory cartridge with 1MB of Flash memory.
When fitting or removing a memory cartridge, the power to
the printer must be off!

Installation of Memory Cartridge

Ensure that the On/Off switch on the printer is off (0).
1
Open the top cover by pressing the two locks on either side.
2
Remove the cartridge slot cover located to the left of the media roll.
3
Be careful not to drop it inside the printer.
Ensure that the switch at the front short side of the cartridge is in its
4
lower position.
Insert the memory cartridge into the cartridge slot. Its slightly curved
5
shape ensures that the cartridge can only be fitted correctly. Push
firmly to seat the cartridge.
Firmly close the top cover and switch on the power.
6
Insert memory
cartridge
Switch down
8 EasyCoder PC4 User's Guide
