Battery Charging - Icom IC-F61M Instruction Manual

D Rapid charging with the BC-121N+AD-100
The optonal BC-121N allows up to 6 battery packs to be charged
smultaneously. The followng tems are addtonally requred.
• Sx AD-100 charger adapter
• An AC adapter (BC-157) or a DC power cable (OPC-656)
*See the nstructon
manual for detals of
the charger LED nd-
caton, operaton, etc.
AC adapter
(Purchase
separately.)
DC power cable
(OPC-656)
(Connect wth the
DC power supply;
13.8 V/at least 7 A)
Transceiver
Battery pack
IMPORTANT!:
Ensure the gude
lobes on the
battery pack are
correctly algned
wth the gude
rals nsde of the
charger adapter.

BATTERY CHARGING

Turn power OFF
AD-100
adapters are n-
stalled n each slot.
Gude rals
4
1
2
3
4
5
6
7
8
charger
9
10
11
12
13
14
15
Lobes 16
17
18
19
20
32
