TABLE OF CONTENTS
IMPORTANT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
CAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
TABLE OF CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
I Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
I Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
I Seaparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
iv
SUPPLIED ACCESSORIES
q
w
t
o
!0
!1
q Microphone (HM-100) . . . . 1
w Microphone hanger and
screw set . . . . . . . . . . . 1 set
e Microphone cable . . . . . . . 1
r DC power cable
(OPC-345) . . . . . . . . . . . . . 1
t Mounting bracket . . . . . . . . 1
y Bracket bolts . . . . . . . . . . . 4
NOTE: Some versions include the SP-22
D Function name stickers
Use these to label the programmable function keys ([P0] to
[P4]) according to their assigned functions.
r
e
LCD-STICKER
y
u
i
!3
!2
u Mounting screws (M5 × 12) 4
i Self-tapping screws
(M5 × 20) . . . . . . . . . . . . . . 4
o Flat washers . . . . . . . . . . . 4
!0 Spring washers . . . . . . . . . 4
!1 Nuts . . . . . . . . . . . . . . . . . . 4
!2 Fuses (15A) . . . . . . . . . . . . 2
!3 Function name stickers 1 set
.
EXTERNAL SPEAKER
