Summary of Contents for Da-Lite TENSIONED DUAL MASKING ELECTROL
- Page 1 The Da-Lite Difference. DA-LITE SCREEN COMPANY, INC. Instruction Book for 3100 North Detroit Street Post Office Box 137 TensIoned dUAL MAsKInG eLecTroL® Warsaw, Indiana 46581-0137 Phone: 574-267-8101 800-622-3737 Fax: 574-267-7804 Toll Free Fax: 877-325-4832 www.da-lite.com e-mail: info@da-lite.com...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using your video equipment, basic safety precautions should always be followed, including the following: 1. Read and understand all instructions before using. 2. Position the cord so that it will not be tripped over, pulled, or contact hot surfaces. -
Page 3: Pre-Installation
PRE-INSTALLATION 1. Carefully unpack screen and remove outer wrapping from case. 2. Make sure to recheck measurements of screen location before installation. 3. Remove center support brackets (on 8' and wider screens only), reverse brackets and reinstall flush with the top of the box. - Page 4 Surface travel is stopped automatically in the fully opened and closed positions by limit switches that are properly ad- justed at Da-Lite. Should it be necessary to adjust for more or less drop of picture, proceed in the following manner: NOTE: Use a screw driver or allen wrench to make adjustments.
- Page 5 Surface travel is stopped automatically in the fully opened and closed positions by limit switches that are properly ad- justed at Da-Lite. Should it be necessary to adjust for more or less drop of picture, proceed in the following manner: NOTE: Use a screw driver or allen wrench to make adjustments.
- Page 6 Offset mounting, recessed above ceiling. May be dropped ceiling. May also be adapted for use with adapted for 1/4" paneling for ceiling. acoustical or other ceiling 3/4" thick but cut to 1/4" thick under screen case and panel. TENSIONED DUAL MASkINg ELECTROL INSTRUCTIONS ® 9" 8-11/16"...
-
Page 7: Troubleshooting
TROUBLESHOOTINg SYMPTOM CAUSE SOLUTION 1. Screen will not operate. (a) Incorrect line voltage. (a) Verify 115-125V (or 220-240V). If insufficient voltage, rewire incom- Motor does not hum. ing electric line. (b) Blown fuse. (b) Replace fuse. (c) Tripped circuit breaker. (c) Reset circuit breaker. - Page 8 EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137 , Warsaw, IN 46581-0137 , (574) 267-8101, (800) 622-3737 .
