  • Page 1 INSTRUCTION BOOK FOR Tensioned Professional Electrol ®...

  • Page 2: Important Safety Instructions

    Important Safety Instructions Pre-Installation When using your video equipment, basic safety precautions Carefully unpack screen. should always be followed, including the following: Make sure to recheck measurements of screen location Read and understand all instructions before using. before installation. Position the cord so that it will not be tripped over, pulled, or Remove instruction cover plate (Fig.

  • Page 3: Installation

    Installation Hangers (If required) See Figure 3 for hanger placement. Make sure hangers are placed to fit into notches of ironing board.. Screens 22' Wide And Under ⁄ " Case Length ÷ 2 Case Length ÷ 2 ⁄ " ⁄ "...
  • Page 4 Installation Install electrical hook up that applies to your unit. Make sure Level unit lengthwise with a carpenter’s plum level. to review your Electrical Installation Checklists and wiring CAUTION! Do Not completely seal in unit. Access room diagrams (included) for either 110 volt switch, 220/240 volt must be allowed for motor repair or fabric replacement.
  • Page 5 Tensioned Professional Electrol® Installation 9 1/2" 11 5⁄16" Reinforced Motor End Electrical Outlet Box Suggested Methods of Installation Rafters Ceiling Type Hanger 2" Moulding Picture Surface Picture Surface 1" x 3" Cleat Picture Surface Ceiling Mount Recessed Above Ceiling Without Hangers...

  • Page 6: Screen Adjustment

    Screen Adjustment Surface travel is stopped automatically in the fully opened and closed positions by limit switches that are properly adjusted at Da-Lite. CAUTION: Contact Da-Lite at 800-622-3737 or 574-267-8101 if screen motor needs adjustment. ATTENTION: Contactez Da-Lite au 800-622-3737 ou au 574-267-8101 au cas le moteur de l'écran a besoin d'être ajusté.

  • Page 7: Troubleshooting

    Visit www.da-lite.com to find installation and troubleshooting tutorials. You will also find a link to Live Chat for interactive support and you can contact us by email at info@da-lite.com or by phone at (800) 622-3737 or (574) 267-8101 with any troubleshooting questions.
  • Page 8 OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137, Warsaw, IN 46581-0137, (574) 267-8101, (800) 622-3737.
