OWNER`S MANUAL
OSBURN 2300 WOODSTOVE
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOODSTOVES
Verified and/or tested following
ULC S627 and UL 1482 Standards by:
Manufactured by : STOVE BUILDER INTERNATIONAL INC.
250, De Copenhague Street, Saint-Augustin-de-Desmaures (Quebec) G3A 2H3
Tel : (418 ) 527-3060
Fax : (418) 527-4311
www.osburn-mfg.com
This  manual  is  available  for  free  download  on  the  manufacturer's  web  site.  It  is  a
copyrighted  document.  Re‐sale  is  strictly  prohibited.  The  manufacturer  may  update  this
manual from time to time and cannot be responsible for problems, injuries, or damages
arising out of the use of information contained in any manual obtained from unauthorized
sources.
READ AND KEEP THIS MANUAL FOR REFERENCE
45434A
Printed in Canada
29-11-2011

Advertisement

Table of Contents
loading

Related Manuals for Osburn 2300

Summary of Contents for Osburn 2300

  • Page 1 OWNER`S MANUAL OSBURN 2300 WOODSTOVE US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOODSTOVES Verified and/or tested following ULC S627 and UL 1482 Standards by: Manufactured by : STOVE BUILDER INTERNATIONAL INC. 250, De Copenhague Street, Saint-Augustin-de-Desmaures (Quebec) G3A 2H3 Tel : (418 ) 527-3060 Fax : (418) 527-4311 www.osburn-mfg.com...

  • Page 2: Table Of Contents

    CHIMNEY ............................33   BRICK LAYOUT ..........................34   OSBURN LIMITED LIFETIME WARRANTY ................35   REGISTER YOU WARRANTY ONLINE To receive full warranty coverage, you will need to show evidence of the date you purchased your stove. Keep your sales invoice. We also recommend that you register your warranty online at http://www.osburn-mfg.com/warranty-registration.aspx...

  • Page 3: Introduction

    INTRODUCTION SBI INC., one of the most important wood stove and fireplace manufacturers in Canada, congratulates you on your purchase and wishes to help you get maximum satisfaction from your wood stove. In the pages that follow, we will give you advice on wood heating and controlled combustion as well as technical specifications regarding installation, operation and maintenance of the model you have chosen.

  • Page 4: Technical Specifications

    TECHNICAL SPECIFICATIONS Wood Combustible: 500 to 2 300 ft Recommended Surface (46 to 214 m 30 800 BTU/h Heating Capacity* : E.P.A : (9.02 kW) Seasoned cordwood: 85 000BTU/h (24.91kW) 75 % Optimum efficiency : 5.7 g/h Emissions: Colors : Flat Black Flue Pipe Diameter : 6’’...

  • Page 5: Assembly

    ASSEMBLY The Osburn 2300 can be installed on legs or on pedestal. If you chose the model on legs, follow the steps of section A below. If you chose the model on pedestal, follow the steps of section B on the following page.

  • Page 6: Pedestal Assembly

    PEDESTAL ASSEMBLY In order to install the pedestal on your Osburn 2300 wood stove, follow these steps: 1- Put the stove on its back. 2- Remove the two freight supports (A). Keep the bolts and washers. 3- Secure the pedestal to the stove using the 4 screws already installed, and the bolts and washers...

  • Page 7: Ash Drawer Assembly

    Refer to the drawings below for the ash drawer assembly. For the Osburn 2300 on pedestal, all you need to do is insert the ash drawer. You will notice that two screws, as shown below, are used to stop the ash drawer under the firebox.

  • Page 8: Door Adjustment

    DOOR ADJUSTMENT In order for your stove to operate properly, the door should be adjusted periodically to provide an air tight fit. To adjust:  Remove the lock pin (spring pin) by pulling and turning it using pliers ("wise grip") ...

  • Page 9: Door Overlay Assembly

    DOOR OVERLAY ASSEMBLY Your Osburn 2300 must be equipped with a door overlay. In order to install it, secure it to the door using 4 screws (screws #8 – 32 x 5/8’’ pan quadrex, supplied with the owner’s manual) as shown below.

  • Page 10: Installation

    INSTALLATION SAFETY NOTICE  I F THIS STOVE IS NOT PROPERLY INSTALLED A HOUSE FIRE MAY RESULT O REDUCE THE RISK OF FIRE FOLLOW THE INSTALLATION INSTRUCTIONS AILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE BODILY INJURY OR EVEN DEATH ...

  • Page 11: Clearances To Combustibles And Floor Protector

    CLEARANCES TO COMBUSTIBLES AND FLOOR PROTECTOR To install your appliance correctly, it is extremely important to respect all clearances to any combustibles as indicated on your stove’s certification label. Clearances to combustible materials (see figure 1.3 to match each letter to a clearance) CLEARANCES (SINGLE WALL PIPE) CANADA 15’’...
  • Page 12 FIGURE 1.3 Clearances to combustible materials and floor protection...

  • Page 13: Floor Protector

    FLOOR PROTECTOR If the stove is to be installed on top of a combustible floor, it must be guarded by a non combustible material as shown on figure 1.3 (see the dotted line area). FLOOR PROTECTOR* CANADA 8’’ (203 mm) – Note 1 N/A (Canada only) 8’’...
  • Page 14 Clearances of not less than 1" (25 mm) and not more than 3" (76 mm) between the bottom of the shield and the floor and not less than 3" (76 mm) between the top of the shield and the ceiling must be respected to allow vertical air circulation behind the shield. The shield must extend 20"...
  • Page 15 Graphic 1 A- Minimum clearance required between the appliance and an unshielded combustible ceiling. B- 20 in. (500 mm) minimum; C- 1 in. (25 mm) minimum; D- Between 1 in. and 3 in. (25 mm and 75 mm); E- 3 in.(75 mm) minimum; F- 18 in.
  • Page 16 Graphic 2 A- 1 in.(25 mm) minimum; 1- Combustible wall; 2- Non-combustible spacers; 4- 0.024’’ (0.61mm) sheet metal. Graphic 3 A- 1 in. (25 mm) minimum; 1- Combustible wall; 2- Non-combustible spacers; 3- Non-combustible support; 5- Ceramic tile or non-combustible material. Graphic 4 A- 1 in.
  • Page 17 Graphic 5 A- 1 in. (25 mm) minimum; 1- Combustible wall; 2- Non-combustible spacers; 3- Brick. Graphique 6 A- 1 in. (25 mm) minimum; 1- Combustible wall; 2- Non-combustible spacers; 3- 0.024’’ (0.61 mm) thick sheet metal; 4- Brick.

  • Page 18: Chimney

    CHIMNEY Your wood stove may be hooked up with a factory built or masonry chimney. If you are using a factory built chimney, it must comply with UL 103 or ULC S629 standards; therefore it must be a Type HT (2100°F). It is extremely important that it be installed according to the manufacturer's specifications.

  • Page 19: Chimney Connector (Stove Pipe)

    CHIMNEY CONNECTOR (STOVE PIPE) Your chimney connector (commonly called stove pipe) and chimney must have the same diameter as the stove’s exhaust outlet. The stove pipe must be made of aluminized or cold roll steel with a minimum 24-gauge thickness (0.021" or 0.53 mm). It is strictly forbidden to use galvanized steel. The following recommendations may be useful for the installation of your chimney connector: ...
  • Page 20 FIGURE 2.3 (B) Minimum Slope We recommend that you use two 45 degree elbows instead Avoid 90 degree eblows...

  • Page 21: Typical Installations

    TYPICAL INSTALLATIONS FACTORY BUILT CHIMNEY: RAIN CAP ROOF FLASHING 18" CLEARANCE RADIATI WALL RADIATION SHIELD WALL SUPPORT CEILING Vertical installation Wall installation...
  • Page 22 MASONRY CHIMNEY: You can also install your stove using your existing masonry chimney. To do so, follow the guidelines below. You may want to use a factory-built thimble, or construct your own brick thimble. If you are using a masonry chimney, it is important that it be built in compliance with the specifications of the Building Code in your region.
  • Page 23 FACTORY BUILT THIMBLE:...
  • Page 24 BRICK THIMBLE:...

  • Page 25: Outside Combustion Air

    OUTSIDE COMBUSTION AIR Your OSBURN stove is approved to be installed with an outside air intake which is necessary for a mobile home. This type of installation is also required in air tight houses and houses with negative pressure problems. You can purchase this option through your OSBURN dealer.

  • Page 26: Woodstove Utilisation

    WOODSTOVE UTILISATION Your heating unit was designed to burn wood only; no other materials should be burnt. Wastes and other flammable materials should not be burnt in your wood stove. Any type of wood may be used in your stove, but specific varieties have better energy yields than others. Please consult the following table in order to make the best possible choice.

  • Page 27: Testing Your Wood

    Smaller pieces of wood will dry faster. All logs exceeding 6" in diameter should be split. The wood should not be stored directly on the ground. Air should circulate through the cord. A 24" to 48" air space should be left between each row of logs, which should be placed in the sunniest location possible.

  • Page 28: Heating

    If you push on it until it stops the combustion air is reduced to a minimum. Your OSBURN stove burnt between .954 kg\h et 2.556 kg\h. of wood during EPA testing. Real operating conditions may give very different results than those obtained in the lab according to the species of wood used, its moisture content, the size and density of the pieces, the length of the chimney, altitude and outside temperature.

  • Page 29: Reloading

    RELOADING Once you have obtained a good bed of embers, you should reload the unit. In order to do so, open the air controls to maximum a few seconds prior to opening the stove's door. Then proceed by opening the door very slowly; open it one or two inches for 5 to 10 seconds, before opening it completely to increase the draught and thus eliminate the smoke which is stagnant in a state of slow combustion in the stove.

  • Page 30: Use Of The Bypass Damper

    USE OF THE BYPASS DAMPER Your stove is equipped with a bypass damper. This feature should be used, if needed, upon start-up of the stove to help heat-up the chimney faster. The bypass damper should be closed as soon as there is a fire going inside the firebox and smoke is moving upward through the exhaust system.

  • Page 31: Creosote Formation And Need For Removal

    CREOSOTE FORMATION AND NEED FOR REMOVAL When wood is burned slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creosote. The creosote vapours condense in the relatively cool chimney flue of a slow-burning fire. As a result, creosote residue accumulates on the flue lining.

  • Page 32: Fan (Blower) Operation

    Do not abuse the glass door by striking or slamming shut. Do not use the stove if the glass is broken.  If the glass on your stove breaks, replace only with glazing supplied from the Osburn dealer.

  • Page 33: Gasketing

    Refer to page 18 of the present manual for the paint curing process. CHIMNEY Call a professional chimney sweep, or go to your local Osburn distributor, purchase a chimney brush, and have the chimney cleaned. Regular chimney (flue) maintenance, as well...

  • Page 34: Brick Layout

    BRICK LAYOUT ITEM PART # DESCRIPTION 29015 4 X 9 BRICK PL36022 4 X 5 3/8 BRICK PL36054 4 X 9 BRICK (CUT) SE16059 ASH DUMP CAP...

  • Page 36: Osburn Limited Lifetime Warranty

    Proof of purchase (dated bill of sale), model name and serial number must be supplied when making any warranty claim to your OSBURN dealer.
