OWNER'S MANUAL
OSBURN 2300 WOOD STOVE
Distributed by
Glen Dimplex Australasia
NEW ZEALAND
AUSTRALIA
38 Harris Road, East Tamaki, Auckland
Unit 2,205 Abbotts Road
Ph: 09 274 8265
Fax 09 274 8472
Dandenong South, Victoria 3175
Email:sales@glendimplex.co.nz
Ph: 1 300 566 816 Fax 8787 3570
www.masportheating.co.nz
Email: sales@glendimplex.com.au
www.masportheating.com.au
READ AND KEEP THIS MANUAL FOR REFERENCE
45128
Advertisement
Table of Contents
Related Manuals for Osburn Osburn 2300
Summary of Contents for Osburn Osburn 2300
- Page 1 OWNER’S MANUAL OSBURN 2300 WOOD STOVE Distributed by Glen Dimplex Australasia NEW ZEALAND AUSTRALIA 38 Harris Road, East Tamaki, Auckland Unit 2,205 Abbotts Road Ph: 09 274 8265 Fax 09 274 8472 Dandenong South, Victoria 3175 Email:sales@glendimplex.co.nz Ph: 1 300 566 816 Fax 8787 3570 www.masportheating.co.nz...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION....................... 2 TECHNICAL SPECIFICATIONS ..................3 ASSEMBLY ........................4 DOOR ADJUSTMENT ....................5 INSTALLATION......................... 6 POSITIONING THE STOVE..................7 FLOOR PROTECTOR....................7 CLEARANCES TO HEAT-SENSITIVE MATERIALS............. 8 REDUCED CLEARANCES USING SHIELDING ............9 OPERATING AND MAINTENANCE INSTRUCTIONS............ 11 TESTING YOUR WOOD ..................... -
Page 3: Introduction
INTRODUCTION Glen Dimplex Australasia congratulates you on your purchase and wishes to help you get maximum satisfaction from your wood stove. In the pages that follow, we will give you advice on wood heating and controlled combustion as well as technical specifications regarding installation, operation and maintenance of the model you have chosen. -
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS Combustible: Wood Maximum heat output – hardwood (Australia): 8.5 kW 68 % Efficiency – hardwood (Australia): 2.0 g/kg Emissions – hardwood (Australia): Color : Metallic black 152 mm Flue Spigot Diameter : Standard Flue system : Minimum Flue Height (from floor protector): 4.6 meters 508 mm Maximum Log Length :... -
Page 5: Assembly
ASSEMBLY Pedestal Base Installation: 1. Slide the ash pan in position. Side Panels : 1. Start by fixing the front part of the decorative side in the two clips welded on the sides of the fire box. 2. Then, fix the back of the decorative side with two screws and washers supplied. -
Page 6: Door Adjustment
DOOR ADJUSTMENT In order for your stove to operate properly, the door should be adjusted periodically to provide an air tight fit. To adjust: • Remove the lock pin (spring pin) by pulling and turning it using pliers ("Vise grip") •... -
Page 7: Installation
INSTALLATION IT IS RECOMMEND THAT THE INSTALLATION OF YOUR OSBURN WOODFIRE BE CARRIED OUT BY A QUALIFIED SPECIALIST INSTALLER. IF ANY ELECTRICAL WORK IS REQUIRED, IT MUST BE CARRIED OUT BY A LICENSED ELECTRICIAN. WARNING: The instructions pertaining to the installation of your wood stove comply with the AS/NZS 2918 standard. -
Page 8: Positioning The Stove
POSITIONING THE STOVE It is very important to position the wood stove as close as possible to the chimney, and in an area that will favour the most efficient heat distribution possible throughout the house. The stove must therefore be installed in the room where the most time is spent, and in the most spacious room possible. -
Page 9: Clearances To Heat-Sensitive Materials
It is of outmost importance that the clearances to heat-sensitive materials be carefully maintained upon installation of the stove you have selected. Refer to the table below : CLEARANCES TO HEAT SENSITIVE MATERIALS Model OSBURN 2300 150mm 500mm 220mm 300mm 200mm •... -
Page 10: Reduced Clearances Using Shielding
REDUCED CLEARANCES USING SHIELDING You may decrease the minimum clearances to heat-sensitive materials by installing heat radiation shields between the walls or the ceiling and the stove. These heat radiation shields must be installed permanently, and must be made of a heat-resistant or heat- tolerant material. - Page 11 FLUE TERMINATION REQUIREMENTS...
-
Page 12: Operating And Maintenance Instructions
OPERATING AND MAINTENANCE INSTRUCTIONS Keep these instructions for future reference. WARNING: • ANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRITING BY THE AS/NZS 4013. TESTING AUTHORITY IS CONSIDERED AS BREACHING • DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS TO START OR REKINDLE THE FIRE •... -
Page 13: Testing Your Wood
Many problems related to the operation of a wood stove are caused by the fact that the wood used is too damp or has dried in poor conditions. These problems can be: • problems lighting the fire • creosote build-up causing flue fires •... -
Page 14: Heating
Before igniting the paper and kindling wood, it is recommended that you warm up the flue. This is done in order to avoid back draught problems often due to negative pressure in the house. If such is the case, open a window slightly near the stove and twist together a few sheets of newspaper into a torch. -
Page 15: Reloading
RELOADING Once you have obtained a good bed of embers, you should reload the unit. In order to do so, open the air control to its maximum for approximately 15 seconds prior to opening the stove door. Then, proceed by opening the door very slowly; open it by 20 to 40 mm for 10 to 15 seconds before opening it completely. -
Page 16: Use Of The Bypass Damper
USE OF THE BYPASS DAMPER Your stove is equipped with a bypass damper. This feature should be used, if needed, upon start-up of the stove to help heat-up the flue faster. The bypass damper should be closed as soon as there is a fire going inside the firebox and smoke is moving upward through the exhaust system. -
Page 17: Creosote Formation And Need For Removal
CREOSOTE FORMATION AND NEED FOR REMOVAL When wood is burnt slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creosote. The creosote vapours condense in the relatively cool flue of a slow-burning fire. As a result, creosote residue accumulates on the flue system. When ignited, this creosote makes an extremely hot fire. -
Page 18: Ash Disposal Using Ash Drawer
ASH DISPOSAL USING ASH DRAWER 1. Make sure the fire is out, and the stove is cold. 2. Lift the ash dump plug at the left rear of the firebox by hooking the poker through the loop on the cover and lifting up. 3. -
Page 19: Maintenance
MAINTENANCE Your Osburn stove is a high efficiency stove and therefore require little maintenance. It is important to perform a visual inspection of the stove every time it is emptied, in order to insure that no part has been damaged, in which case repairs must be performed immediately. -
Page 20: Brick Notes
BRICK NOTES Figure 7: Firebrick layout... -
Page 21: Paint
STOVE BUILDER INTERNATIONAL INC. 1700, Léon-Harmel, Québec (Québec) G1N 4R9 Tel : (418) 527-3060 Fax : (418) 527-4311 www.osburn-mfg.com Distributed by Glen Dimplex Australasia AUSTRALIA NEW ZEALAND Unit 2,205 Abbotts Road 38 Harris Road, East Tamaki, Auckland Dandenong South, Victoria 3175...
