Osburn OB01601 Owner's Manual

Hide thumbs Also See for OB01601:
Table of Contents

Advertisement

Quick Links

1600 INSERT
250, de Copenhague, Saint-Augustin-de-Desmaures (Quebec) G3A 2H3
After-sale service: 418-908-8002
This manual is available for free download on the manufacturer's web site. It is a copyrighted
document. Re-sale is strictly prohibited. The manufacturer may update this manual from time to
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
OWNER'S MANUAL
Manufactured by: STOVE BUILDER INTERNATIONAL INC
www.osburn-mfg.com
(OB01601 model)
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED WOOD
INSERT
OREGON DEPARTEMENT
ENVIRONMENTAL QUALITY
Verified and tested following
ULC S628, UL 907, UL 1482 Standards by an
accredited laboratory
E-mail: tech@sbi-international.com
.
45084A
05-08-2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OB01601 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Osburn OB01601

Summary of Contents for Osburn OB01601

  • Page 1 OWNER’S MANUAL 1600 INSERT (OB01601 model) US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOOD INSERT OREGON DEPARTEMENT ENVIRONMENTAL QUALITY Verified and tested following ULC S628, UL 907, UL 1482 Standards by an accredited laboratory Manufactured by: STOVE BUILDER INTERNATIONAL INC...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS GENERAL INFORMATION ON 1600 INSERT (OB01601) ..........4 APPLIANCE PERFORMANCE ....................4 GENERAL FEATURES ......................... 5 INSTALLATION ........................7 DOOR OVERLAY INSTALLATION ................... 8 DOOR ADJUSTMENT ........................9 PRE-INSTALLATION REQUIREMENTS ................. 10 MINIMUM MASONRY OPENING, CLEARANCES TO COMBUSTIBLES, AND FLOOR PROTECTOR ..........................
  • Page 3 INTRODUCTION SBI INC., one of the most important wood stove and fireplace manufacturers in Canada, congratulates you on your purchase and wishes to help you get maximum satisfaction from your wood insert. In the pages that follow, we will give you advice on wood heating and controlled combustion as well as technical specifications regarding installation, operation and maintenance of the model you have chosen.

  • Page 4: General Information On 1600 Insert (Ob01601)

    GENERAL INFORMATION ON 1600 INSERT (OB01601) APPLIANCE PERFORMANCE Fuel type Dry cordwood Recommended heating area 500 to 1,800 ft (46 to 167 m Firebox volume 2.0 ft (0.057 m Maximum burn time Maximum heat output (dry cordwood) 65,000 BTU/h (19.0 kW) (2)(3) Overall heat output rate (min.

  • Page 5: General Features

    GENERAL FEATURES Maximum log length 17 in (432 mm) east-west* Flue outlet diameter 6 in (152 mm) Recommended connector pipe diameter 6 in (152 mm) Type of chimney ULC-S635, CAN/ULC-S640, UL1777 Baffle material C-Cast Approved for alcove installation Not approved ‡...

  • Page 7: Installation

    INSTALLATION SAFETY NOTICE • I F THIS INSERT IS NOT PROPERLY INSTALLED A HOUSE FIRE MAY RESULT O REDUCE THE RISK OF FIRE FOLLOW THE INSTALLATION INSTRUCTIONS AILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE BODILY INJURY OR EVEN DEATH •...

  • Page 8: Door Overlay Installation

    DOOR OVERLAY INSTALLATION In order to complete the assembly of your Osburn 1600 wood insert, you need to install the door overlay. See figure 1 below for installation instructions: Position the overlay on the door frame and fix it in place from behind using the 4 screws.

  • Page 9: Door Adjustment

    DOOR ADJUSTMENT In order for your insert to operate properly, the door should be adjusted periodically to provide an air tight fit. To adjust: • Remove the lock pin (spring pin) by pulling and turning it using pliers ("wise grip") •...

  • Page 10: Pre-Installation Requirements

    PRE-INSTALLATION REQUIREMENTS MASONRY & ZERO CLEARANCE REQUIREMENTS The masonry fireplace must meet the minimum code requirements, or NFPA 21.1 or the equivalent for a safe installation. Contact your local Building Inspector for requirements in your area. An inspection of the fireplace should include the following: 1.

  • Page 11: Minimum Masonry Opening, Clearances To Combustibles, And Floor Protector

    6. ADJACENT COMBUSTIBLES: The fireplace should be inspected to make sure that there is adequate clearance to combustibles, both exposed combustibles to the top, side, and front as well as concealed combustibles, in the chimney and mantle area. Your local inspector should have information on whether older fireplaces are of adequate construction.
  • Page 12 MAXIMUM MAXIMUM MINIMUM MASONRY STANDARD LARGE OPENING FACEPLATE FACEPLATE 22.125" (562 mm) 29" (737 mm) 32" (813 mm) 26.375" (670 mm) 44" (1118 mm) 50" (1270 mm) 14.375" (365 mm) CLEARANCES 16’’ (406 mm) 10’’ (254 mm) 16’’ (406 mm) 22’’...

  • Page 13: Venting Requirements

    VENTING REQUIREMENTS The flue is a critical component to a satisfactory installation. Your insert will attain its best performance if installed with a flue that generates its own draft. The minimum venting requirement will be the installation of a flue connector from the insert into the first tile of the chimney (see Figure 2.3).

  • Page 14: Installation Instructions

    INSTALLATION INSTRUCTIONS Inspect the fireplace according to the safety information and fireplace requirements and have it cleaned and/or upgraded as necessary. If the installation of the unit renders the existing damper control inaccessible, it will be necessary to either secure the damper wide open or remove it entirely. An inaccessible damper which may fall shut later could cause smoke to enter the room.
  • Page 15 POSITIONING THE UNIT: The more extended the insert, the greater the heat transfer to the room. When installed as an extended insert, the front edge of the air jacket will be installed flush with the fireplace facing. Otherwise the unit can be moved back as much as 2.5"...
  • Page 16 If lag-bolts and anchors are to be used to secure the insert, the hole locations should be marked with the unit in place. Remove the unit and locate the anchors. Remove the faceplate panels from their box and assemble according to these faceplate instructions: Remove the slide from within the air jacket.
  • Page 17 INSTALLATION ON FACEPLATE: Attach the mitred corners of trim together using the corner brackets. Slide the assembled trim over the edge of the faceplate. See Figures 8 and 9. Attach the left and right sides to the top with corner brackets supplied. Slip the trim over the faceplate and snap the eight faceplate trim clips in place (see Figure 8).
  • Page 18 Push the air control (A) in, all the way. Slide the adjustable faceplate sleeve back into its original location until the faceplate fits tightly against the fireplace facing. See Figure 10. One 7/16" (11mm) open end wrench should be used to turn the nut (B), located above the cooktop in the center, up so that it securely fastens the adjustable faceplate sleeve to the top air jacket.

  • Page 19: Operation

    OPERATION Your heating unit was designed to burn wood only; no other materials should be burnt. Wastes and other flammable materials should not be burnt in your wood insert. Any type of wood may be used in your insert, but specific varieties have better energy yields than others.

  • Page 20: Testing Your Wood

    TESTING YOUR WOOD When the insert is thoroughly warmed, place one piece of split wood (about five inches in diameter) parallel to the door on the bed of red embers. Keep the air control full open by pulling on it and close the door. If ignition of the piece is accomplished within 90 seconds from the time if was placed in the insert, your wood is correctly dried.

  • Page 21: Heating

    If you move it completely to the left, it is fully close. Your OSBURN insert burnt between .979 kg\h and 4.4 kg\h. of wood during EPA testing. Real operating conditions may give very different results than those obtained in the lab according to the species of wood used, its moisture content, the size and density of the pieces, the length of the chimney, altitude and outside temperature.

  • Page 22: Creosote Formation And Need For Removal

    CREOSOTE FORMATION AND NEED FOR REMOVAL When wood is burned slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creosote. The creosote vapours condense in the relatively cool chimney flue of a slow-burning fire. As a result, creosote residue accumulates on the flue lining.

  • Page 23: Maintenance

    Do not abuse the glass door by striking or slamming shut. Do not use the insert if the glass is broken. • If the glass on your insert breaks, replace only with glazing supplied from the OSBURN dealer.

  • Page 24: Secondary Air Tube Replacement

    Note that any tube can be replaced without disturbing the baffle. The air tubes are identified for placement as follows: Model Type of tube Front ► 22 holes of 1/4" Osburn 1600 Insert...

  • Page 25: Exploded Diagram And Parts List

    EXPLODED DIAGRAM AND PARTS LIST...
  • Page 26 RHEOSTAT KNOB 44087 RHEOSTAT NUT 44093 ROCKER SWITCH 2 POSITION (ON - OFF) WITH GOLD CONTACT SE45084 INSTRUCTION MANUEL KIT OSBURN 1600 INSERT OA10305 MEDIUM FACEPLATE KIT (32" X 44") OA10310 LARGE FACEPLATE KIT (32" X 50") OA10300 REGULAR FACEPLATE KIT (29" X 44")
  • Page 27 Item Description OA10128 BLACK LARGE FACEPLATE TRIMS (32" X 50") OA10126 BRUSHED NICKEL FACEPLATE TRIMS (32" X 44") OA10122 BLACK FACEPLATE TRIMS (29" X 44") OA10121 BRASS FACEPLATE TRIMS (29" X 44") OA10124 BRASS FACEPLATE TRIMS (32" X 44") OA10129 BRUSHED NICKEL LARGE FACEPLATE TRIMS (32"...

  • Page 28: Osburn Limited Lifetime Warranty

    Labour cost and repair work to the account of the manufacturer are based on a predetermined rate schedule and must not exceed the wholesale price of the replacement part. Shall your unit or a components be defective, contact immediately your OSBURN dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling: •...
