OWNER`S MANUAL
OSBURN MODEL 1000 FREESTANDING STOVE
Distributed by
Glen Dimplex Australasia
NEW ZEALAND
AUSTRALIA
38 Harris Road, East Tamaki, Auckland
Unit 2,205 Abbotts Road
Ph: 09 274 8265
Fax 09 274 8472
Dandenong South, Victoria 3175
Email:sales@glendimplex.co.nz
Ph: 1 300 566 816 Fax 8787 3570
www.masportheating.co.nz
Email: sales@glendimplex.com.au
www.masportheating.com.au
READ AND KEEP THIS MANUAL FOR REFERENCE
45126A
20-10-2011

Advertisement

Table of Contents
loading

Summary of Contents for Osburn 1000

  • Page 1 OWNER`S MANUAL OSBURN MODEL 1000 FREESTANDING STOVE Distributed by Glen Dimplex Australasia NEW ZEALAND AUSTRALIA 38 Harris Road, East Tamaki, Auckland Unit 2,205 Abbotts Road Ph: 09 274 8265 Fax 09 274 8472 Dandenong South, Victoria 3175 Email:sales@glendimplex.co.nz Ph: 1 300 566 816 Fax 8787 3570 www.masportheating.co.nz...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........................3   TECHNICAL SPECIFICATIONS ....................4   DOOR OVERLAY INSTALLATION ..................... 5   DOOR ADJUSTMENT ........................6   INSTALLATION ..........................7   POSITIONING THE STOVE ......................8   FLOOR PROTECTOR ........................8   CLEARANCES TO HEAT-SENSITIVE MATERIALS ..............9  ...
  • Page 4: Introduction

    INTRODUCTION Glen Dimplex Australasia congratulates you on your purchase and wishes to help you get maximum satisfaction from your wood stove. In the pages that follow, we will give you advice on wood heating and controlled combustion as well as technical specifications regarding installation, operation and maintenance of the model you have chosen.
  • Page 5: Technical Specifications

    TECHNICAL SPECIFICATIONS Combustible: Wood Maximum heat output – hardwood (Australia): 15 kW Efficiency – hardwood (Australia): 66 % 1.5 g/kg Emissions – hardwood (Australia): Metallic black Color : Flue Spigot Diameter : 152 mm Standard Flue system : Minimum Flue Height (from floor protector): 4.6 meters 406 mm Maximum Log Length :...
  • Page 6: Door Overlay Installation

    DOOR OVERLAY INSTALLATION In order to complete the assembly of your Osburn 1000 wood stove, you need to install the door overlay. See figure 1 below for installation instructions : 1- Position the overlay on the door frame and fix it in place from behind using the 4 screws.
  • Page 7: Door Adjustment

    DOOR ADJUSTMENT In order for your stove to operate properly, the door should be adjusted periodically to provide an air tight fit. To adjust:  Remove the lock pin (spring pin) by pulling and turning it using pliers ("Vise grip") ...
  • Page 8: Installation

    INSTALLATION IT IS RECOMMENDED THAT THE INSTALLATION OF YOUR OSBURN WOODFIRE BE CARRIED OUT BY A QUALIFIED SPECIALIST INSTALLER. IF ANY ELECTRICAL WORK IS REQUIRED, IT MUST BE CARRIED OUT BY A LICENSED ELECTRICIAN. WARNING: The instructions pertaining to the installation of your wood stove comply with the AS/NZS 2918 standard.
  • Page 9: Positioning The Stove

    POSITIONING THE STOVE It is very important to position the wood stove as close as possible to the chimney, and in an area that will favour the most efficient heat distribution possible throughout the house. The stove must therefore be installed in the room where the most time is spent, and in the most spacious room possible.
  • Page 10: Clearances To Heat-Sensitive Materials

    It is of outmost importance that the clearances to heat-sensitive materials be carefully maintained upon installation of the stove you have selected. Refer to the table below : CLEARANCES TO HEAT SENSITIVE MATERIALS Model OSBURN 1000 100mm 350mm 150mm 300mm 100mm* *200 mm from door opening.
  • Page 11: Reduced Clearances Using Shielding

    REDUCED CLEARANCES USING SHIELDING You may decrease the minimum clearances to heat-sensitive materials by installing heat radiation shields between the walls or the ceiling and the stove. These heat radiation shields must be installed permanently, and must be made of a heat-resistant or heat- tolerant material.
  • Page 12 FLUE TERMINATION REQUIREMENTS...
  • Page 13: Operating And Maintenance Instructions

    OPERATING AND MAINTENANCE INSTRUCTIONS Keep these instructions for future reference. WARNING:  ANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRITING BY THE AS/NZS 4013. TESTING AUTHORITY IS CONSIDERED AS BREACHING  DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS TO START OR REKINDLE THE FIRE ...
  • Page 14: Testing Your Wood

    Many problems related to the operation of a wood stove are caused by the fact that the wood used is too damp or has dried in poor conditions. These problems can be:  problems lighting the fire  creosote build-up causing flue fires ...
  • Page 15: Lithing The Fire

    LITHING THE FIRE After making sure that the stove air intake controls are fully open to the left (located on the front of the stove, see Figure 3), place several rumpled sheets of paper in the center of the combustion chamber. Place 8 to 10 pieces of small dry kindling wood over the paper in the form of a tent.
  • Page 16: Heating

    Your OSBURN stove may burn differently according to the species of wood used, its moisture content, the size and density of the pieces, the length of the flue, the altitude, and outside temperature.
  • Page 17: Reloading

    RELOADING Once you have obtained a good bed of embers, you should reload the unit. In order to do so, open the air control to its maximum for approximately 15 seconds prior to opening the stove door. Then, proceed by opening the door very slowly; open it by 20 to 40 mm for 10 to 15 seconds before opening it completely.
  • Page 18: Ash Disposal

    ASH DISPOSAL Ashes should be removed from the stove every few days or when ashes get to 50 to 75mm deep. Always empty the stove when it is cold, such as in the morning. Always dispose of ashes in a metal container with a tight fitting lid. Place this container on a non combustible floor or on the ground, well away from all heat-sensitive materials, pending final disposal.
  • Page 19 Cover the plug with the remaining ashes and continue operation of your stove as usual. The Ash Drawer is shown in Figure 4 and can be removed by pulling it out toward you. Lift the Ash Drawer slightly or the pedestal base may get scratched. Close the rear half of the Ash Drawer lid to prevent spillage.
  • Page 20: Paint

    (2) of paint successively. REPLACEMENT PARTS The table below presents a listing of the main replaceable components on your stove. Those components can be purchased via your OSBURN dealer. ITEM PART # DESCRIPTION...
